2023 Ford Lobo Service and Repair Manual

This factory service and repair manual for the 2023 Ford Lobo lists eight trims, Lariat, Limited, Platinum, Raptor, Raptor High, Tremor, Tremor High and XLT, in two body styles, the four-door crew cab pickup and the two-door standard cab pickup. The engines are a turbocharged 3.5L DOHC V6 of 213 cubic inches, a naturally aspirated 5.0L DOHC V8 of 302 cubic inches, and the full hybrid version of the turbocharged 3.5L V6, all on gasoline. Procedures, specifications, torque values, wiring diagrams and diagnostics are set out for each of the three, with the hybrid treated separately where it differs.

Engines covered

• 3.5L V6 (213 cu in) — DOHC, turbocharged, gasoline
• 5.0L V8 (302 cu in) — DOHC, naturally aspirated, gasoline
• 3.5L V6 full hybrid (213 cu in) — DOHC, turbocharged, gasoline

Body styles covered

• 4-door crew cab pickup
• 2-door standard cab pickup

Trims covered

• Lariat
• Limited
• Platinum
• Raptor
• Raptor High
• Tremor
• Tremor High
• XLT

Known issues on the 2023 Lobo. Seven recalls are on the federal record for the 2023 Lobo. The front axle pinion may not have been heat-treated; the steering wheel clock spring may have an insufficient weld; and the passenger-side instrument panel top cover may keep the air bag from deploying as intended. Owners have registered 541 complaints with NHTSA for this model year. Front axle procedures and torque values, steering column wiring diagrams and air bag diagnostics in the manual cover the systems named, on the 3.5L, hybrid and 5.0L trucks alike.
