2019 Ford Lobo Service and Repair Manual

This factory service and repair manual for the 2019 Ford Lobo applies to four trims, King Ranch, Lariat, Platinum and XLT, in the four-door crew cab pickup and the two-door standard cab pickup. Power comes from either the turbocharged 3.5L DOHC V6 of 213 cubic inches or the naturally aspirated 5.0L DOHC V8 of 302 cubic inches, both on gasoline. The manual's procedures, specifications, torque values, wiring diagrams and diagnostics are split by engine first and by cab second, which is the order in which a technician usually needs them.

Engines covered

• 3.5L V6 (213 cu in) — DOHC, turbocharged, gasoline
• 5.0L V8 (302 cu in) — DOHC, naturally aspirated, gasoline

Body styles covered

• 4-door crew cab pickup
• 2-door standard cab pickup

Trims covered

• King Ranch
• Lariat
• Platinum
• XLT

Known issues on the 2019 Lobo. Six recalls are on federal record for 2019. A poor electrical connection means the rearview camera may work only intermittently; the fastener securing the power distribution box cable and the battery monitoring system eyelet is the subject of a battery cable campaign; and the daytime running lamps on trucks with high series LED headlamps and autolamp are covered by another. Owners have submitted 1590 complaints to NHTSA on the 2019 model. Camera and battery cable wiring diagrams, exterior lighting diagnostics and seat procedures are in the manual for the 3.5L V6 and 5.0L V8.
