2002 Ford Lobo Service and Repair Manual
This factory service and repair manual for the 2002 Ford Lobo spans six trims, Base, Harley-Davidson Edition, King Ranch, Lariat, Sport FX4 and XLT, on three bodies: the four-door crew cab pickup, the two-door standard cab pickup and the four-door extended cab pickup. Under the hood the choices are the 5.4L SOHC V8 of 330 cubic inches, the 4.6L SOHC V8 of 281 cubic inches, and a supercharged 5.4L SOHC V8, every one of them gasoline. Procedures, specifications, torque values, wiring diagrams and diagnostics are provided for each engine, with the supercharged 5.4L treated separately from its naturally aspirated counterpart.
Engines covered
- 5.4L V8 (330 cu in) — SOHC, naturally aspirated, gasoline
- 4.6L V8 (281 cu in) — SOHC, naturally aspirated, gasoline
- 5.4L V8 (330 cu in) — SOHC, supercharged, gasoline
Body styles covered
- 4-door crew cab pickup
- 2-door standard cab pickup
- 4-door extended cab pickup
Trims covered
- Base
- Harley-Davidson Edition
- King Ranch
- Lariat
- Sport FX4
- XLT
Known issues on the 2002 Lobo. Five recalls are on the federal record for the 2002 Lobo: the fuel tank mounting campaign, the speed control deactivation switch that may overheat, smoke or burn, and three aftermarket lamp campaigns covering headlamps built without the amber side reflex reflector and combination corner and bumper lamp assemblies. Owners have lodged 964 complaints with NHTSA against this model year. The manual's wiring diagrams for the speed control circuit, its diagnostics for the switch itself and its fuel tank procedures and torque values apply across the naturally aspirated and supercharged 5.4L and the 4.6L V8.
FORD IS RECALLING CERTAIN 1997 THROUGH 2003 MODEL YEAR FORD F-150, 2004 MODEL YEAR FORD F-150 HERITAGE, 1997 THROUGH 1999 MODEL YEAR F-250 LESS THAN 8,500 LBS. GROSS VEHICLE WEIGHT
K2 MOTOR IS RECALLING 1,921 AFTERMARKET HEADLAMPS OF VARIOUS MODELS SOLD FOR USE ON THE ABOVE LISTED VEHICLES. THESE HEADLAMPS ARE MISSING THE AMBER SIDE REFLEX REFLECTOR WHICH FA
DOPE, INC. IS RECALLING 42,540 COMBINATION CORNER AND BUMPER LAMP ASSEMBLIES OF VARIOUS PART NUMBERS SOLD FOR USE AS AFTERMARKET EQUIPMENT FOR VARIOUS PASSENGER VEHICLES. THESE HE
ON CERTAIN PICKUP TRUCKS AND SPORT UTILITY VEHICLES EQUIPPED WITH SPEED CONTROL, THE SPEED CONTROL DEACTIVATION SWITCH MAY OVERHEAT, SMOKE, OR BURN.
SABERSPORT IS RECALLING 16,270 COMBINATION CORNER AND BUMPER LAMP ASSEMBLIES OF VARIOUS PART NUMBERS SOLD FOR USE AS AFTERMARKET EQUIPMENT FOR VARIOUS PASSENGER VEHICLES. THESE HE
TL* THE CONTACT OWNED A 2002 FORD F-150. WHILE DRIVING APPROXIMATELY 55 MPH, THE DRIVER CRASHED INTO THE REAR OF A TRAILER THAT WAS STALLED IN THE MIDDLE OF AN INTERSECTION. THE IN
WOKE UP AT 1AM ONE 4-1-2018 TO MY FORD F 150 ON FIRE DRIVERS SIDE FRONT UNDER THE HOOD. UNKNOW TO US OUR LOCAL SHERIFF HAD SPOTTED THE FIRE AND ALREADY CALLED THE FIRE DEPARTMENT.
Showing the 2 most serious of 964 complaints filed with NHTSA.
