2020 Ford Lobo Service and Repair Manual

This factory service and repair manual for the 2020 Ford Lobo covers three trims, Lariat, Platinum and XLT, on the four-door crew cab pickup and the two-door standard cab pickup, with two gasoline engines: the turbocharged 3.5L DOHC V6, 213 cubic inches, and the naturally aspirated 5.0L DOHC V8, 302 cubic inches. The pairing of a boosted six with a naturally aspirated eight means the manual keeps two sets of procedures, specifications, torque values, wiring diagrams and diagnostics side by side, one for each engine, with the body and chassis material shared between the two cab styles.

Engines covered

• 3.5L V6 (213 cu in) — DOHC, turbocharged, gasoline
• 5.0L V8 (302 cu in) — DOHC, naturally aspirated, gasoline

Body styles covered

• 4-door crew cab pickup
• 2-door standard cab pickup

Trims covered

• Lariat
• Platinum
• XLT

Known issues on the 2020 Lobo. The 2020 truck has eight recalls on federal record. A spare tire that could have been damaged when it was mounted on its rim is one; an incorrect attachment nut on the battery positive cable at the starter is another; a third is the fastener securing the power distribution box cable and battery monitoring system eyelet. NHTSA's complaint count for the 2020 model year is 828. Starter and battery cable wiring diagrams, tire and wheel specifications and wiper linkage procedures cover those items for the 3.5L V6 and 5.0L V8.
