2021 Ford Lobo Service and Repair Manual

This factory service and repair manual for the 2021 Ford Lobo covers three engines: the turbocharged 3.5L DOHC V6 of 213 cubic inches, the naturally aspirated 5.0L DOHC V8 of 302 cubic inches, and a full hybrid version of the turbocharged 3.5L V6, all gasoline. Four trims are listed, Lariat, Limited, Platinum and XLT, on the four-door crew cab pickup and the two-door standard cab pickup. The hybrid brings its own procedures, specifications, torque values, wiring diagrams and diagnostics, separate from those of the conventional V6 and the V8.

Engines covered

• 3.5L V6 (213 cu in) — DOHC, turbocharged, gasoline
• 5.0L V8 (302 cu in) — DOHC, naturally aspirated, gasoline
• 3.5L V6 full hybrid (213 cu in) — DOHC, turbocharged, gasoline

Body styles covered

• 4-door crew cab pickup
• 2-door standard cab pickup

Trims covered

• Lariat
• Limited
• Platinum
• XLT

Known issues on the 2021 Lobo. For the 2021 truck the federal record lists eight recalls. Two-piece driveshafts may have been improperly assembled and could separate; a diagnostic trouble code for low transmission fluid pressure may activate falsely; and on trucks with a single exhaust system, contact with the rear axle housing may damage the parking brake wiring harness. Owners have logged 1,201 complaints with NHTSA on the 2021 truck. Driveshaft procedures and torque values, transmission diagnostics and parking brake wiring diagrams cover those systems on the 3.5L, hybrid and 5.0L trucks.
