2020 Ford Explorer Service and Repair Manual

This factory service and repair manual for the 2020 Ford Explorer covers four engines: the 3.3L V6 full hybrid and the 3.3L V6 running on flex-fuel, both naturally aspirated with dual overhead camshafts, plus the turbocharged 2.3L inline-four and the turbocharged 3.0L V6, also dual overhead-cam gasoline engines. The 4-door sport utility is listed in six trims: Base, Limited, Limited Hybrid, Platinum, ST and XLT. Hybrid system procedures sit alongside conventional engine coverage, and the transmission, driveline, brakes, steering, suspension, body and electrical systems receive specifications, torque values, wiring diagrams and diagnostics.

Engines covered

• 3.3L V6 full hybrid (204 cu in) — DOHC, naturally aspirated, gasoline
• 2.3L inline-four (140 cu in) — DOHC, turbocharged, gasoline
• 3.3L V6 (204 cu in) — DOHC, naturally aspirated, flex-fuel
• 3.0L V6 (181 cu in) — DOHC, turbocharged, gasoline

Body styles covered

• 4-door sport utility

Trims covered

• Base
• Limited
• Limited Hybrid
• Platinum
• ST
• XLT

Known issues on the 2020 Explorer. Eight recalls are on federal record for the 2020 model year. The drive shaft on all-wheel-drive trucks with the 10-speed automatic could fracture along its weld seam and allow a rollaway; the right-hand motor mount fasteners might be incorrectly tightened and loosen until the axle disconnected; and rear lower control arm bolts that skipped heat treatment could break and cause a loss of steering control. Owners have filed 1,201 complaints with NHTSA, most on the power train at 456, the electrical system at 138 and back-over prevention at 61. Drive shaft, motor mount and rear suspension torque values are in the manual.
