1987 Ford F-250 Service and Repair Manual

This factory service and repair manual for the 1987 Ford F-250 applies to the 5.8L V8, the 5.0L V8, the 7.5L V8, the 6.9L V8 diesel and the 4.9L inline-six, five naturally aspirated OHV engines carried into the year unchanged in displacement. The two bodies are the two-door standard cab pickup and the two-door extended cab pickup, and the entry trim is badged Custom, sitting below XL and XLT Lariat for three trims in all. Engine, driveline, chassis and body procedures, with their specifications, torque values, wiring diagrams and diagnostics, are written for these combinations and no others.

Engines covered

• 5.8L V8 (351 cu in) — OHV, naturally aspirated, gasoline
• 5.0L V8 (302 cu in) — OHV, naturally aspirated, gasoline
• 7.5L V8 (460 cu in) — OHV, naturally aspirated, gasoline
• 6.9L V8 (420 cu in) — OHV, naturally aspirated, diesel
• 4.9L inline-six (300 cu in) — OHV, naturally aspirated, gasoline

Body styles covered

• 2-door standard cab pickup
• 2-door extended cab pickup

Trims covered

• Custom
• XL
• XLT Lariat

Known issues on the 1987 F-250. Two recalls stand on the federal record for the 1987 F-250. Lug nut cone angles on some trucks do not match the wheel seating angles, so nuts can loosen in service until a wheel separates; the other is the spring lock fuel line coupling that can disengage and lose fuel. Owners have filed 48 complaints with NHTSA, 13 of them on the electrical system, nine on the service brakes and six on the engine and cooling. Wheel and hub torque values, fuel line procedures, brake specifications and wiring diagrams in the manual cover the areas involved.
