1985 Ford F-250 Service and Repair Manual

This factory service and repair manual for the 1985 Ford F-250 documents a lineup that kept its five engines from the previous year: the 5.8L V8, the 5.0L V8, the 7.5L V8, the 6.9L V8 diesel and the 4.9L inline-six, the last available for propane or gasoline. Standard cab and extended cab two-door pickups are the two bodies, and three trims were offered, Base, XL and XLT Lariat, with the Lariat name back at the top of the range this year. The reference treats gasoline and diesel powertrains side by side, with separate procedures, specifications and torque values wherever the two diverge.

Engines covered

• 5.8L V8 (351 cu in) — OHV, naturally aspirated, gasoline
• 5.0L V8 (302 cu in) — OHV, naturally aspirated, gasoline
• 4.9L inline-six (300 cu in) — OHV, naturally aspirated, LPG (propane) or gasoline
• 7.5L V8 (460 cu in) — OHV, naturally aspirated, gasoline
• 6.9L V8 (420 cu in) — OHV, naturally aspirated, diesel

Body styles covered

• 2-door extended cab pickup
• 2-door standard cab pickup

Trims covered

• Base
• XL
• XLT Lariat

Known issues on the 1985 F-250. Two recalls are on federal record for the 1985 F-250. The first traces to metal burrs and sharp edges on fuel rails that could damage adjacent O-ring seals during assembly, leaving the engine to leak fuel while running; the second covers trucks built without the nose shield on the midship fuel tank, which failed the federal fuel-system-integrity impact test. Owners have filed 34 complaints with NHTSA, led by nine on the electrical system, five on the service brakes and four on the engine and cooling. Fuel injection, fuel tank mounting, charging and brake procedures, specifications and wiring diagrams in the manual cover those areas.
