2016 Ram 4500 Service and Repair Manual

This factory service and repair manual for the 2016 Ram 4500 covers a truck offered in three trims, Laramie, SLT and Tradesman. Two engines were listed: a 6.4L gasoline V8 of 392 cubic inches without forced induction, and a 6.7L turbodiesel inline-six of 408 cubic inches, both with overhead valves. The body choices were a 2-door conventional cab and chassis or a 4-door crew cab and chassis. Specifications, procedures and diagnostics address both engines, the drivetrain and the chassis systems.

Engines covered

• 6.4L V8 (392 cu in) — OHV, naturally aspirated, gasoline
• 6.7L inline-six (408 cu in) — OHV, turbocharged, diesel

Body styles covered

• 2-door cab & chassis, conventional
• 4-door cab & chassis, crew cab

Trims covered

• Laramie
• SLT
• Tradesman

Known issues on the 2016 4500. Seven recalls appear on the record for the 2016 4500. Certain 2016 Ram 4500 trucks built within a set window could have a transfer case whose main output shaft was misshapen during manufacture; a fractured shaft could cut drive power and keep the truck from holding in park. Dealers installed a new transfer case. Certain trucks with a column shifter could have their brake shift interlock stick open after long brake application in park. On certain others, cruise control might not disengage after a wiring short. One complaint was filed, under structure. The manual gives drivetrain, transmission and electrical procedures, torque values and wiring diagrams.
