1986 Ford E-250 Econoline Service and Repair Manual
This factory service and repair manual for the 1986 Ford E-250 Econoline documents three gasoline engines, the 5.8L OHV V8, the 5.0L OHV V8 and the 4.9L OHV inline-six, in Base and XL trim. Four bodies are covered, from the standard passenger van through the extended cargo van. Fuel delivery, cooling, brakes, steering and body electrics each have their own section, with procedures, specifications, torque values, wiring diagrams and diagnostics, so a 1986 van can be traced end to end without leaving the book.
Engines covered
- 5.8L V8 (351 cu in) — OHV, naturally aspirated, gasoline
- 5.0L V8 (302 cu in) — OHV, naturally aspirated, gasoline
- 4.9L inline-six (300 cu in) — OHV, naturally aspirated, gasoline
Body styles covered
- 2-door standard passenger van
- 2-door standard cargo van
- 2-door extended passenger van
- 2-door extended cargo van
Trims covered
- Base
- XL
Known issues on the 1986 E-250 Econoline. The 1986 van collected six recalls. Two of them deal with fuel escaping where it should not: a spring lock fuel line coupling that may not be fully engaged, and a vapor valve grommet at the top of the front tank that can split under installed load. A third concerns the steering drag link ball joint, whose rubber can deteriorate until the joint separates. Eight owner complaints are logged with NHTSA, mostly on the electrical and fuel systems. Fuel line service, tank removal and steering linkage inspection are covered by the manual's procedures and torque values.
