2009 Ford Crown Victoria Service and Repair Manual

Regular price $42.99 USD
Covers all 2009 Crown Victoria trims — Fleet Sedan 4-Door, Police Interceptor Sedan 4-Door, LX Sedan 4-Door +1 more ·
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.7 · Trusted by 14,000+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Looks like an incomplete random collection of service manual pages with technical service bulletins mixed in, all in random order. This is nothing like what their site advertises.

I see that key engine, transmission, brake and suspension sections are extremely incomplete or completely missing.

Very disappointing.

I will dispute this with my credit card, and I will lodge a complaint with the various authorities, and I am going to show this to my attorneys, they are going to have fun with these goons.

J
FactoryManual
James Baker

Easy to buy and download. Chris Winfrey was very helpful. Thanks.

D
FactoryManual
Donald Duck

F off

D
FactoryManual
David D Wieland

The manual seems to be complete and was easy to download. The pages are images, however, and not searchable.

A
FactoryManual
Anonymous

Where were wiring diagrams?

A
FactoryManual
Anonymous

Very difficult to navigate seems like similar information is in several random locations

A
FactoryManual
Anonymous

All other content is as promised

A
FactoryManual
Anonymous

Very hard to navigate. Could not even find a index

T
FactoryManual
TERRY MUICH

The download I received was a complete waste of my money. Was not even close to what it was represented as. I thought I was getting a proper service repair manual. What I got was a collection of service bulletins. I sent an email to your company right after I looked through it requesting my money back. Have yet to hear a response. Terry Muich

R
FactoryManual
Ricky Coley

Not a hard copy manual and the file is to big too load on my computer.

J
FactoryManual
John Puzak

I'm trying to download the manual to my laptop. Can't get a table of contents on my phone. Might have a better review the

After directions from from factory manuals,
I downloaded Adobe Acrobat-working great. Great customer service!!!

R
FactoryManual
Richard Musser

easy

D
FactoryManual
Donald Folmar

More detailed than I thought, still trying to navigate through it, not what I thought it would be, thought it would be more like the Haynes manual.

N
FactoryManual
Nathaniel Footman Jr

Delivery via wifi great.

A
FactoryManual
Anonymous

Great

D
FactoryManual
David Bacon

It was much larger than i expected. 5 documents at 12k pages each. Its not something ill actually be able read but its easy enough to find what you need..
The Ford F250 manual is much easier to navigate at just over 8000 pages.
If i spend the money for Adobe Acrobat Professional ill be able to break it down into manageable bits.
Both manuals area great value for the money.

S
FactoryManual
Susanne Dubois

Manual ok. Very hard to find info pertaining to my vehicle

M
FactoryManual
Mark Stypinski

Easy to use and great to look up tech specs.

S
FactoryManual
Stuart Clancy

Easy to find the exact manual for your vehicle, great directions for the download process for the less than savvy internet users.

D
FactoryManual
Daniel Arvola

The manual is awesome!

A
FactoryManual
Anonymous

Pretty good manual, bookmarking could be a little better

T
FactoryManual
Thomas Downs

I am unable to open the manual. I guess I didn't process something right.

S
FactoryManual
Stanislav Bilev

Got the manual almost immediately.

A
FactoryManual
Anonymous

I need a printed 2015 Ford Taurus 3.5 engine repair manual either Chilton or Haynes

J
FactoryManual
James Foley

Excellent. Now I can actually start working on my cars again with confidence. YouTube videos really are inadequate.

M
FactoryManual
Mark Schultz

Schematics were not high resolution making the markings and names difficult to read when zoomed in. Improvement is needed. Otherwise it is a good document.

S
FactoryManual
Scott Martin

Vary easy

W
FactoryManual
Werner A Wozniak

Very satisfied with my purchase. Has all clear details and fixes like the oem factory manual have. Thanks and God bless you.

A
FactoryManual
Anonymous

.

A
FactoryManual
Anonymous

Finding and ordering the manual for my vehicle was very easy

M
FactoryManual
Michael Willis

I wasn’t sure why I needed this to be a PDF, but it was apparent once I got it. It includes what would be thousands of pages if it were in print. The links take you to wherever you need to go in the text.

A
FactoryManual
Anonymous

I didn’t realize I would have a link in an email to click to get another email with another link to download.

This factory service and repair manual for the 2009 Ford Crown Victoria is for the four-door sedan in four trims, Fleet, LWB, LX and Police Interceptor, powered in every case by the naturally aspirated 4.6L single overhead cam V8 on flex-fuel or gasoline. The procedures, specifications, torque values, wiring diagrams and diagnostics cover that engine and its fuel system and then the steering column, brakes, suspension, power train and electrical circuits of the car. With one engine listed, the fuel system section applies to every car, and the steering column procedures are the ones this year's recall record points to.

Engines covered

  • 4.6L V8 (281 cu in) — SOHC, naturally aspirated, flex-fuel or gasoline

Body styles covered

  • 4-door sedan

Trims covered

  • Fleet
  • LWB
  • LX
  • Police Interceptor

Known issues on the 2009 Crown Victoria. Two recalls are on federal record for the 2009 Crown Victoria, both in the steering column: the upper intermediate shaft can separate if it was serviced improperly, and the lower column bearing on cars from certain states can come apart, either of which can cost the driver steering control. Owners have filed 44 complaints with NHTSA, with steering at 17, the fuel system at 11 and the power train at seven. The steering column procedures and torque values, the fuel system diagnostics and the transmission section of this manual are where those complaints lead.

NHTSA #13V38500029/08/2013Component: STEERING

Ford is recalling certain model year 2005-2011 Ford Crown Victoria (including Crown Victoria Police Interceptors), Mercury Grand Marquis, and Lincoln Town Car vehicles. The affecte

TSB #11029052

Ford and Lincoln vehicles equipped with wired keyless entry keypad systems and accessory wireless keyless entry keypad systems may or may not come with a wallet card containing the master code. Unlike the integrated wired keypad, the access

TSB #10254138

All accessory stick-on keyless entry keypads come with a wallet card containing the master code. If the accessory keypad was factory installed, this card will be placed in the glove box and should be handed to the vehicles owner during ini

TSB #10205037

Inpected or repaired under 13R01 - Requests for recall service action under 13S08

TSB #10204997

4R75E Transmission - Grinding/Whine/Vibration/Gear Slippage - Serrvice Kit available

TSB #10109070

The Powertrain Control/Emissions Diagnosis (PC/ED) manual has been revised for diagnosing electronic throttle bodies (ETBs). The ETC_ACT and ETC_DSD PIDs should not used to diagnose possible ETB concerns. The IDS has a limited refresh rate

TSB #10075262

4R75E TRANSMISSION - GRINDING/WHINE/VIBRATION/GEAR SLIPPAGE - SERVICE KIT AVAILABLE ISSUE A service kit has been released to assist with proper repair of the 4R75E transmission in 2008 Mark LT, 2008-2010 F-150, 2008-2010 / 2013-2014 E-Serie

TSB #10056701

FORD/LINCOLN/MERCURY: FAILURE OF PLANETARY GEAR ASSEMBLY IS DUE TO TRANSMISSION, ON CERTAIN VEHICLES, EXHIBITING GRINDING, GEAR SLIPPAGE, WHINE TYPE NOISE, VIBRATION, WHILE DRIVING OR LOSS OF REVERSE. *PE

TSB #10056191

FORD/LINCOLN/MERCURY: THE INDICATOR MAY ILLUMINATE OVERDRIVE OFF AND/OR SLIPPING IN 3RD OR NO 4TH GEAR, DUE TO DIRECT CLUTCH FAILURE AND DIAGNOSTIC TROUBLE CODE (DTC) P0733 AND/OR P0734. MODEL 2008-2013 MARK LT, F-150, CROWN VICTORIA, GRAND

Showing the 8 most recent of 13 technical service bulletins on file with NHTSA.

20150804Component: AIR BAGSCrash reported1 injured

TL* THE CONTACT OWNED A 2009 FORD CROWN VICTORIA. WHILE DRIVING AT APPROXIMATELY 20 MPH APPROACHING AN INTERSECTION, ANOTHER VEHICLE RAN THE RED LIGHT AND CRASHED INTO THE FRONT DR

20120416Component: AIR BAGSCrash reportedFire reported

CHARLESTON COUNTY SHERIFF'S OFFICE MARKED PATROL CAR. DRIVER LOST CONTROL AT HIGH SPEED. SLID ACROSS THE MEDIAN.SPUN 180 DEGREES WAS STRUCK IN THE REAR BY ONCOMING VEHICLE. CONTI

Showing the 2 most serious of 44 complaints filed with NHTSA.
