2006 Chevrolet Express 1500 Service and Repair Manual
Regular price
$29.99 USD
Unit price
Covers all 2006 Express 1500 trims — Base Standard Cargo Van 3-Door, LS Standard Passenger Van 4-Door, LS Standard Passenger Van 3-Door +3 more ·
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.7
·
Trusted by 14,000+ mechanics & DIYers
End of preview
Unlock the full manual
Complete repair procedures
Wiring diagrams & schematics
Torque specifications
Full search & bookmarks
$29.99
2006 Chevrolet Express 1500 Service and Repair Manual
Regular price
$29.99 USD
Unit price
Regular price
$29.99 USD
Unit price
This factory service and repair manual for the 2006 Chevrolet Express 1500 has four bodies to account for: cargo and passenger vans in three-door and four-door configurations, sold as Base, LS or LT. Under the hood sit a 5.3L V8 of 325 cubic inches and a 4.3L V6 of 262, both pushrod gasoline units without forced induction. Door count matters most in the body and wiring sections, where latch, hinge and circuit routing differ from one configuration to the next.
Engines covered
- 5.3L V8 (325 cu in) — OHV, naturally aspirated, gasoline
- 4.3L V6 (262 cu in) — OHV, naturally aspirated, gasoline
Body styles covered
- 3-door standard cargo van
- 4-door standard passenger van
- 3-door standard passenger van
- 4-door standard cargo van
Trims covered
- Base
- LS
- LT
Known issues on the 2006 Express 1500. The federal record holds eight recalls for this year. One is a power steering hose built out of specification that can fracture during a hard lock-to-lock maneuver; the leak costs steering assist and, on vans with hydraulic brake boost, braking assist as well. Several others cover platform wheelchair lifts whose interlocks miss the presence of a user, letting the lift move or stow with someone aboard, and one covers belt buckles that will not latch or release. Eighteen complaints are recorded, spread thinly across structure, the electrical system and air bags.
No active recalls
The 2006 Chevrolet Express 1500 has no recalls on file with NHTSA.
This PI communicates the requirement to provide a pico file to receive diagnostic assistance from TAC.
This Preliminary Information communication provides information to the technician about the use of J-35616-64B and Mini 50 terminal test probe, replacement terminals, and terminated leads.
This Preliminary Information communication provides information to the technician about the use of J-35616-64B and Mini 50 terminal test probe, replacement terminals, and terminated leads.
This Preliminary Information communication provides information to the technician about the use of J-35616-64B and Mini 50 terminal test probe, replacement terminals, and terminated leads.
This service bulletin explains how to measure for oil consumption and possible reasons for loss of oil.
This Preliminary Information communication provides information to the technician about the use of J-35616-64B terminal test probe, replacement terminals, and terminated leads. The J-35616-64B is the latest test probe released for checking
This service bulletin explains how to measure for oil consumption and possible reasons for loss of oil.
This service bulletin provides information for dealers/technicians on When and How to Submit a Field Product Report (FPR) (U.S. and Canada Dealers Only).
Showing the 8 most recent of 136 technical service bulletins on file with NHTSA.
THE VEHICLE SECURITY LIGHT COMES ON INTERMITTENTLY FOR YEARS, I THEN CANNOT START THE VEHICLE. I HAVE REPORTED THE PROBLEM TO GM, I HAVE HAD IT TO THE CHEVROLET DEALERSHIP TWICE, W
FAULTY FUEL GAUGE SENSOR ON 2006 CHEVY EXPRESS VAN. MY FUEL GAUGE READ APPROX 1/8TH OF A TANK. THE LOW FUEL LIGHT HAD NOT COME ON. THE VAN STOPPED RUNNING AND COULD NOT BE STA
THE HINGES ON THE DOORS OF CHEVY VANS ARE DEFECTIVE IN THAT THEY ARE IMPROPERLY DESIGNED AND CORRODED AND BECOME DIFFICULT IF NOT IMPOSSIBLE TO OPEN AND CLOSE THE HINGES ARE INVERT
THE HINGES ON THE DOORS OF CHEVY VANS ARE DEFECTIVE IN THAT THEY ARE IMPROPERLY DESIGNED AND CORRODED AND BECOME DIFFICULT IF NOT IMPOSSIBLE TO OPEN AND CLOSE THE HINGES ARE INVERT
Showing the 4 most serious of 6 complaints filed with NHTSA.
