2018 Kia Sportage Service and Repair Manual
Kia built the 2018 Sportage in three engine configurations across five trim levels, and the correct figures change from one to the next. This is the service and repair manual Kia published for the 2018 Sportage model year, not a neighboring year of the same nameplate.
Engines covered
- 2.0L inline-four (122 cu in) — DOHC, turbocharged, gasoline
- 2.0L inline-four (122 cu in) — DOHC, naturally aspirated, gasoline
- 2.4L inline-four — DOHC, naturally aspirated, gasoline
Body styles covered
- 4-door sport utility
Trims covered
- EX
- EX Pack
- LX
- SX Turbo
- SXL
Known issues on the 2018 Sportage. Three recalls are on federal record for this model year. The first covers the gasoline fuel delivery hoses, lines, piping and fittings on Sportages that had previously received an engine replacement under an earlier recall: a fuel leak in the presence of an ignition source can increase the risk of a fire. The second covers trailer hitches on vehicles equipped with a tow hitch, where a fire while parked or driving can increase the risk of injury. The third covers the hydraulic service brakes and the antilock and traction control system, where the electrical circuit in the Hydraulic Electronic Control Unit (HECU) may short-circuit and cause a fire; an engine compartment fire can increase the risk of injury. Owners have filed 215 complaints for the year and Kia has issued 76 technical service bulletins. The factory diagnostic and repair procedures behind each of those systems are here.
From checking fuel line connections after an engine replacement to tracing a fault in the HECU circuit or a routine service on the 2.0L turbo, it keeps you on Kia’s own procedure and the correct specification for your 2018 Sportage.
Kia Motors America (Kia) is recalling certain 2011-2017 Optima, 2012-2017 Sorento and 2011-2018 Sportage vehicles that previously received an engine replacement under recall number 17V-224, warranty, or the Knock Sensor Detection System (KSDS) Product Improvement Campaign. The high pressure fuel pipe that connects to the fuel pump outlet may have been damaged, misaligned or improperly torqued during the engine replacement procedure, possibly causing a fuel leak.
A fuel leak in the presence of an ignition source can increase the risk of a fire.
Kia has notified owners, and dealers will inspect and replace the fuel pipe, as necessary, free of charge. The recall began January 17, 2019. Owners may contact Kia customer service at 1-800-333-4542. Kia's number for this recall is SC172.
Kia Motors America (Kia) is recalling certain 2017-2021 Sportage and Cadenza vehicles. The electrical circuit in the Hydraulic Electronic Control Unit (HECU) may short-circuit, which can cause a fire in the engine compartment.
An engine compartment fire can increase the risk of injury.
Owners are advised to park outside and away from structures as a precaution until the recall repair is complete. Kia will notify owners, and dealers will replace certain fuses in the electrical junction box. Vehicles equipped with an electronic parking brake (EPB) will also receive a HECU software update. Repairs will be performed free of charge. The recall began on April 30, 2021. Owners may contact Kia customer service at 1-800-333-4542. Kia's number for this recall is SC206.
Kia America, Inc. (Kia) is recalling certain 2016-2022 Sorento, 2021-2022 Sorento Hybrid (HEV), 2022-2023 Sorento Plug-In Hybrid (PHEV), and 2017-2022 Sportage vehicles equipped with a tow hitch harness installed as original equipment, or purchased as an accessory through a Kia dealership. Debris and moisture accumulation on the tow hitch harness module printed circuit board (PCB) may cause an electrical short, which can result in a fire.
A fire while parked or driving can increase the risk of injury.
Owners are advised to park outside and away from structures until the recall repair is complete. Dealers will inspect the vehicle, and, as necessary, replace the fuse and/or tow hitch harness module, free of charge. Owner notification letters were mailed August 11, 2023. Owners may contact Kia customer service at 1-800-333-4542. Kia's number for this recall is SC249.
TECHNICAL SERVICE BULLETIN: CUSTOMER SATISFACTION: THEFT DETERRENT IGNITION CYLINDER PROTECTOR AND DECAL INSTALLATION (CS2312) - This bulletin has been revised to include additional information. New/revised sections of this bulletin are ind
VOLUNTARY EMISSIONS SERVICE CAMPAIGN: THETA II 2.4L GDI EMISSIONS: ECM LOGIC IMPROVEMENT (SC340 REVISION 5) - This bulletin has been revised to include additional information. New/revised sections of this bulletin are indicated by a black b
VOLUNTARY EMISSIONS SERVICE CAMPAIGN: OWNER NOTIFICATION (SC340 FLIGHT 105) - This document is the owner notification advising that Kia is conducting a Voluntary Emissions Service Campaign to improve the emissions software logic in the Elec
TECHNICAL SERVICE BULLETIN: VOLUNTARY EMISSIONS SERVICE CAMPAIGN: THETA II 2.4L GDI EMISSION SECM LOGIC IMPROVEMENT (SC340 REV 4) - This bulletin has been revised to include additional information. New/revised sections of this bulletin are
TECHNICAL SERVICE BULLETIN: CUSTOMER SATISFACTION: THEFT DETERRENT IGNITION CYLINDER PROTECTOR AND DECAL INSTALLATION (CS2312) - This bulletin has been revised to include additional information. New/revised sections of this bulletin are ind
CUSTOMER SATISFACTION CAMPAIGN: OWNER NOTIFICATION (CS2312) - This document is the owner notification advising that Kia is conducting Customer Satisfaction Campaign. A software upgrade that addresses the social media theft method has been m
VOLUNTARY EMISSIONS SERVICE CAMPAIGN: OWNER NOTIFICATION (SC340 FLIGHT 103 / QL) - This document is the owner notification advising that Kia is conducting a Voluntary Emissions Service Campaign to improve the emissions software logic in the
TECHNICAL SERVICE BULLETIN: CUSTOMER SATISFACTION: THEFT DETERRENT IGNITION CYLINDER PROTECTOR AND DECAL INSTALLATION (CS2312) - This bulletin provides information to install a Theft Deterrent Ignition Cylinder Protector on certain 2010-202
Showing the 8 most recent of 133 technical service bulletins on file with NHTSA.
THE ENTIRE CAR CAUGHT FIRE. ALL ELECTRIC WIRES CAUGHT FIRE AND THE CAR IT WAS PARK IN MY HOUSE .
ALL ELECTRICAL MALFUNCTION AND LOSS OF STEERING AND BRAKES RESULTING IN HEADING CRASH
I was in a collision and sandwiched in between cars severe front and back damage. No Air bags!
My car was stolen from the Kia challenge
Breaks failed to ingage and caused me to hit the back of the vehicle in front of me.
2018 KIA SPORTAGE 4D 4X4 WHILE IN 'PARK' ROLLED DOWN HOME DRIVEWAY. VEHICLE ROLLED INTO STREET, WHILE WIFE HOLDING ONE YEAR OLD SON DODGED VEHICLE TO AVOID GETTING CRUSHED.
This Kia Sportage's alarm system does not go off when the passenger front window is broken. My car was broken into and the youth stripped the steering column and was able to start my car without needing the key nor having the key within the vehicle. This is a security issue and allows the vehicles to be easily stolen. These safety issues should be address and fixed immediately by Kia. The federal government should also hold Kia responsible for the spike in stolen vehicles across the U.S. see
The contact owned a 2018 Kia Sportage. The contact stated that while driving at approximately 50 MPH, the accelerator pedal was depressed; however, the vehicle failed to accelerate as intended. The contact stated that the vehicle decelerated to approximately 45 MPH, and the contact pulled over to the side of the road and the vehicle caught on fire. The contact and her daughter who was inside the vehicle was able to exit the vehicle safely. The contact stated that the fire had started under the h
The contact owned a 2018 Kia Sportage. The contact stated that while driving at an undisclosed speed, he observed black smoke billowing from the engine compartment, after which the vehicle lost motive power, prompting him and his wife to evacuate the vehicle in the middle of the roadway. While attempting to retrieve important belongings from the vehicle, the contact stated that he heard what sounded to be an explosion within the engine compartment, causing him to fall backward and sprain his ank
My vehicle make and model has been documented to have had engine issues which has caused car fires from the engine compartment from what has been documented this is my best guess.
TL* THE CONTACT OWNED A 2018 KIA SPORTAGE. THE CONTACT STATED THAT WHILE APPROACHING A SCHOOL ZONE AND ENTERING THE SCHOOL LOT AT ABOUT 5 MPH, THERE WAS GREY SMOKE COMING FROM UNDER THE HOOD. THE CONTACT EXIT HIS CHILD FROM THE VEHICLE AND PARKED THE VEHICLE TO INSPECT IT THAT WAS WHEN THE HOOD WAS OPENED. THE CONTACT DISCOVERED THAT THE VEHICLE HAD CAUGHT FIRE. THE FIRE DEPARTMENT WAS CONTACTED. A POLICE REPORT WAS FILED. NO INJURIES WERE SUSTAINED. THE FIRE DEPARTMENT EXTINGUISHED THE FLAMES.
I was driving to work, sitting at a stoplight when my car started releasing smoke from under the hood. All warning lights lit up, the car stalled, and the smoke got darker and more intense. Within a minute, flames started appearing under the front of the vehicle and began spreading towards the back of the car
1. Component or System Malfunction & Availability Component/System Failed: An unidentified component within the engine compartment failed, resulting in a sudden, catastrophic thermal event (engine fire). Odometer Reading: 100,415 miles at the time of the incident. Available for Inspection: No. The vehicle was completely destroyed by the fire and is a total loss. 2. Safety Risk Assessment The vehicle was being driven at highway speeds on a major freeway by my 21-year-old son, Brennan Font, whe
Component/System Failed: An unidentified component within the engine compartment failed, resulting in a sudden, catastrophic thermal event (engine fire). Odometer Reading: 100,415 miles at the time of the incident. Available for Inspection: No. The vehicle was completely destroyed by the fire and is a total loss. 2. Safety Risk Assessment The vehicle was being driven at highway speeds on a major freeway by my [XXX] [XXX [XXX] incident occurred. The sudden presence of heavy smoke and intense
On 1/26/2024 approximately 9am, my husband had been driving on the highway for about 2 hours and pulled over to shut his eyes for a few minutes. He shut off the engine, closed his eyes and immediately smelled smoke. Black smoke began coming from under the hood and quickly got worse. He quickly got out of the car and walked away. He heard a loud pop sound and the engine area was engulfed in flames. He called 911. It took about 10 min for the fire dept to arrive and by then, the fire was being fe
Showing the 15 most serious of 162 complaints filed with NHTSA.
