2008 Kia Sportage Service and Repair Manual
Every specification and tightening sequence in this 2008 Kia Sportage service and repair manual is the one Kia published for this exact year, engine and trim — not a near-enough figure borrowed from an earlier or later Sportage.
Engines covered
- 2.0L inline-four — DOHC, naturally aspirated, gasoline
- 2.7L V6 — DOHC, naturally aspirated, gasoline
Body styles covered
- 4-door sport utility
Trims covered
- EX
- LX
- LX Convenience
- LX Luxury
Known issues on the 2008 Sportage. Two recalls are on federal record for this model year. The first is an electrical system wiring recall covering model year 2008-2009 Sportages manufactured August 9, 2007 to May 13, 2009, and concerns the wire harness cover on the Hydraulic Electronic Control Unit; if the HECU short circuits, there is an increased risk of an engine compartment fire. The second is an exterior lighting recall on the stop lamp switch: failure to illuminate the stop lamps during braking, or inability to disengage the cruise control. Owners have filed 138 complaints for the year and Kia has issued 23 technical service bulletins. Kia’s own diagnostic and repair procedure for each of those systems is what you work from here.
From tracing a short in the HECU wiring to replacing a stop lamp switch or working through a routine service interval, it keeps you on Kia’s own procedure and the correct specification for your 2008 Sportage.
Kia Motors America (Kia) is recalling certain model year 2008-2009 Kia Sportage vehicles manufactured August 9, 2007, to May 13, 2009. The wire harness cover on the Hydraulic Electronic Control Unit (HECU) may be improperly sealed allowing water to get onto the HECU circuit board. If the water is contaminated with salt, such as could occur from melted snow, the wire harness connector pins may corrode and the circuit board may short circuit.
If the HECU short circuits, there is an increased risk of an engine compartment fire.
Kia will notify owners, and dealers will inspect the connector pins for corrosion, if no corrosion is found, the connector cover will be replaced. If corrosion is present, the dealer will replace the HECU assembly and the connector cover, free of charge. The recall began on November 28, 2016. Owners may contact Kia customer service at 1-800-333-4542. Kia's number for this recall is SC138.
Kia Motors Corporation (Kia) is recalling certain model year 2007-2010 Rondo, model year 2007-2011 Sedona, Sorento and Sportage, model year 2010-2011 Soul, model year 2008-2011 Optima, model year 2010 Forte, model year 2007-2009 Amanti, and model year 2009 Borrego vehicles. Originally, in April 2013, Kia recalled 623,658 model year 2007-2010 Rondo and Sportage, model year 2007-2011 Sorento, model year 2007 Sedona, model year 2010-2011 Soul, and model year 2011 Optima vehicles. In September 2013, Kia informed the agency that it was adding an additional 356,719 vehicles to this campaign. The total number of vehicles being recalled is now 980,377. In the affected vehicles, the stop lamp sw
Failure to illuminate the stop lamps during braking or inability to disengage the cruise control could increase the risk of a crash. Additionally, when the ignition is in the 'ON' position, the transmission shifter may be able to be moved out of PARK without first applying the brake. This may lead to unintentional movement of the car which may increase the risk of a crash.
Kia will send an interim notification to owners in May 2013. When parts are available, owners will receive a second notification and dealers will replace the stop lamp switch, free of charge. Owners may contact Kia at 1-800-333-4542. Kia's recall campaign number is SC098.
Kia America, Inc. (Kia) is recalling certain 2008-2009 Sportage vehicles previously recalled under recall 16V-815. An engine compartment fire originating from around the Hydraulic Electronic Control Unit (HECU) may occur while parked or driving.
A fire increases the risk of injury.
Owners are advised to park outside and away from structures and other vehicles until the recall repair has been performed. Dealers will inspect and replace the HECU, its wiring harness, and its fuses, as necessary, free of charge. Owner notification letters were mailed December 22, 2022. Owners may contact Kia customer service at 1-800-333-4542. Kia's number for this recall is SC253.
TECHNICAL SERVICE BULLETIN: TRANSMISSION FLUID APPLICATION GUIDE - This bulletin has been revised to include additional information. New/revised sections of this bulletin are indicated by a black bar in the margin area. This bulletin provid
This bulletin provides information relating to the correct transmission fluid type and fill quantity requirement for each Kia model. A flush is required ONLY when a transmission is replaced.
TECHNICAL SERVICE BULLETIN: TRANSMISSION FLUID APPLICATION GUIDE - This bulletin provides information relating to the correct transmission fluid type and fill quantity requirement for each Kia model. A flush is required ONLY when a transmis
TECHNICAL SERVICE BULLETIN: INFORMATION FOR HEADLAMP CONDENSATION AND MOISTURE - This bulletin has been revised to include additional information. New/revised sections of this bulletin are indicated by a black bar in the margin area. This b
TSB - USE OF AFTERMARKET USB CHARGING CABLES IN USB/12V PORTS - This article provides information regarding the use of USB ports and 12V power outlets to connect/charge mobile phones. Customers may experience issues with their head units th
PITSTOP - ENGINE COMPONENT RE-USE GUIDELINES - In general, parts and components removed during engine repairs should be considered serviceable, and should be thoroughly cleaned and transferred to the new engine.
TSB: MANDATORY REPLACEMENT OF LOCKING/SECURITY HARDWARE - By design, certain fasteners, which are designed to lock into place once fully attached, are utilized in various Kia models and are strictly intended for ?one time use.? Some example
TSB: MANDATORY REPLACEMENT OF LOCKING/SECURITY HARDWARE - By design, certain fasteners utilized in various Kia models are strictly intended for ?one time use?. Though not limited to the following, some examples are: axle shaft nuts with sta
Showing the 8 most recent of 24 technical service bulletins on file with NHTSA.
LAST MARCH, I WAS TRYING TO STOP TO AVOID REAR ENDING A VEHICLE TURNING LEFT INTO AN APARTMENT COMPLEX. I WAS DOING LESS THAN 25MPH WHEN I SAW HER BRAKE LIGHTS AND TURN SIGNAL. ADDITIONALLY, I HAD PLENTY OF TIME AND DISTANCE TO STOP SAFELY. HOWEVER, AS I DEPRESSED THE BRAKE THE ESC, BRAKE WARNING AND BRAKE LIGHTS ALL CAME ON AND THE CAR DID NOT SLOW DOWN. I PRESSED HARDER AND HARDER UNTIL THE PEDAL WAS TO THE FLOOR. AT THIS POINT THEY LOCKED UP PREVENTING ME FROM STEERING AWAY FROM THE CAR THAT
ANOTHER VEHICLE TURNED IN FRONT OF ME AND MY CAR IMPACTED THE OTHER VEHICLES PASSENGER SIDE. THERE WAS NO AIR BAG DEPLOYMENT. MY KIA SPORTAGE WAS DECLARED TOTALED. *TR
The radiator fan component was smoking. The car is available at anytime for inspection. I definitely feared that the car was going to explode in front of my baby cousins and elderly Aunt. The car has not been reproduced or confirmed by a dealship or independent service center. It also has not been inpected by manufacturer or police, insurance. The vehicle was not going faster than 30 mph, when parked, the radiator expelled the all the water on floor. It began to let out white smoke, and than
CAR WAS PARKED FOR REPAIRS AND NOT DRIVEN FOR MANY MONTHS OTHER THAN MOVING AROUND OUR PARKING AREA DUE TO DASHBOARD LIGHTS OF ABS, ESC, TRACTION CONTROL, BRAKE LIGHTS LIT. HAD DIAGNOSTICS DONE ON CAR DUE TO ALL LIGHTS ON DASH LIGHTING, ABS, BRAKE, ESC, TRACTION CONTROL. DIAGNOSTICS VIA SHORKEY KIA SHOWED ABS BAD ALONG WITH OIL PAN RUSTING DUE TO WISHING TO GET IT ROAD WORTHY AND INSPECTED. REPLACED OIL PAN AND MOVED CAR OUT OF GARAGE AND IN TO PARKING AREA IN FRONT OF SECOND GARAGE DOOR NEAR H
12/03/17, 03:15 A.M. WHILE PARKED, NOT RUNNING, VEHICLE CAUGHT FIRE UNDER THE HOOD AND BECAME FULLY ENGULFED. VEHICLE HAD BEEN PARKED FOR SEVERAL HOURS PRIOR TO THIS INCIDENT. CAR WAS COMPLETELY DESTROYED. RESIDENCE WAS BUILT WITH VINYL SIDING, AND FRONT OF HOUSE WAS DAMAGED (MELTED VINYL). PARKED AT PRIVATE RESIDENCE. FAMILY ASLEEP INSIDE RESIDENCE WHEN FIRE ERUPTED. FOR 2 WEEKS PRIOR TO FIRE, THE ABS INDICATOR LAMP ON THE DASH PANEL WAS ILLUMINATED. BRAKES HAD BEEN INSPECTED, AND WERE IN GOO
TL* THE CONTACT OWNS A 2008 KIA SPORTAGE. UPON STARTING THE VEHICLE, IT MADE AN ABNORMAL NOISE. THE CONTACT WAS ABLE TO GET THE VEHICLE TO START AFTER MORE THAN TWO ATTEMPTS. THE VEHICLE WAS TAKEN TO AN INDEPENDENT MECHANIC WHO WAS UNABLE TO REPLICATE AND DIAGNOSE THE FAILURE. UPON STARTING THE VEHICLE, SMOKE EMITTED FROM THE HOOD OF THE VEHICLE. A FIRE ERUPTED AND EXTINGUISHED ITSELF. THE VEHICLE WAS UNABLE TO BE DRIVEN DUE TO THE FAILURE AND FIRE. THE VEHICLE WAS PARKED AT THE CONTACT'S RESIDE
VEHICLE WAS SITTING FOR HOURS IN DRIVEWAY. SMOKE BEGAN POURING FROM UNDER HOOD AND DAMAGED UNDERHOOD ACCESSORIES SUCH AS HEADLAMP HOUSING,ABS MODULE, PAINT, WINDSHIELD WASHER RESERVOIR. THE WIRING HARNESS WAS DAMAGED, THE EXTERIOR PAINT WAS BLISTERED AND NOW THE VEHICLE CANNOT BE DRIVEN. THE FIRE APPARENTLY BEGAN IN THE ABS MODULE AT THE RIGHT FRONT WHEEL APRON. EVERYTHING PLASTIC IS DAMAGED AND SOOT COVERS MOST OF THE UNDERHOOD COMPONENTS. THE VEHICLE HAS 48K MILES ON IT AND HAS NEVER BEEN IN A
THIS IS PART 2 OF 3... WE GOT A NEW BATTERY INSTALLED AT ADVANCED AUTO. CAR RAN FINE. THE NEXT MORNING , SHE STARTED THE CAR AND THEN WENT INTO THE HOUSE. MY NIECE WAS THERE AND SAID SHE HEARD A POP AND LOOK OUTSIDE TO SEE THE CAR ON FIRE. THE WHOLE FRONT END INCLUDING THE PASSENGER COMPARTMENT WAS BURNT TO A CRISP. I BELIEVE WHAT HAPPENED WAS A FAULTY PART IN THE ABS (CAUSING THE LIGHT TO COME ON) WAS SHORTING OR SOMETHING AND THAT KEPT DRAINING THE BATTERY. WITH THE BATTERY LOW, THE
SHE IS 73 YEARS OLD AND ON A FIXED INCOME. SHE HAS ALREADY PAID THOUSANDS FOR THE CAR AND NOW DOES NOT HAVE A CAR DUE TO A FAULTY PART. NO CAR SHOULD CATCH ON FIRE DUE TO NORMAL USE. NOW SHE IS GOING TO HAVE TO FIND A WAY TO PAY FOR ANOTHER CAR. HOPEFULLY THAT CAR MANUFACTURER PRODUCES A VEHICLE THAT DOES NOT JUST CATCH FIRE AT RANDOM AND IF IT DOES, THEY TAKE CREDIT FOR BUILDING AND SELLING YOU A VEHICLE WITH A FAULT THAT IS THERE OWN. SHE STRUGGLED TO PAY THOUSANDS OF DOLLARS FOR A CAR TH
THIS WILL BE 1 OF 3 PART STATEMENT... ABOUT A WEEK AGO (GIVE OR TAKE A FEW DAYS), A COUPLE OF MY MOTHER'S 2008 KIA SPORTAGE'S DASH LIGHTS CAME ON. THE ABS LIGHT, THE ESC LIGHT, AND I THINK ONE OTHER (POSSIBLY THE TRACTION CONTROL LIGHT BUT MIND YOU THIS IS NOT MY CAR AND I AM NOT THAT FAMILIAR WITH HER DASH). SHE WAS TOLD THAT THERE WAS A RECALL FOR A PART THAT WAS CAUSING ONE OF THE LIGHTS TO COME ON (I BELIEVE THE ESC LIGHT). SHE TOOK THE CAR TO GET THE PART REPLACED, HOWEVER, THE LIGHTS
TL* THE CONTACT OWNED A 2008 KIA SPORTAGE. THE CONTACT STATED THE VEHICLE CAUGHT FIRE. A FIRE REPORT WAS FILED. THE FIRE DEPARTMENT EXTINGUISHED THE FIRE. NO INJURIES WERE SUSTAINED. THE VEHICLE WAS DESTROYED. THE VIN AND FAILURE MILEAGE WERE NOT AVAILABLE. ..UPDATED 10/26/16 *BF...UPDATED 11/09/16 *BF .. *JS
MY SISTER IN LAW'S 08 KIA SPORTAGE EX HAD ALL THE DASH WARNING LIGHTS COME ON, THE CODE SHOWED P0501 WHEEL SPEED SENSOR MALFUNCTION. I REPLACED RT FRT SENSOR AND STILL SAME CODE. TOOK IT TO LOCAL SHOP AND THEY SAID SOMETHING IS SHORTED BECAUSE THEY CAN'T READ ALL THE LIGHTS ON. I CHECKED SOME FUSES BUT FOUND NONE BLOWN. IT SEEMED LIKE THE BRAKES WERE A LITTLE WEAK AND I DROVE IT FOR A TEST AND NOTICED IT WAS PULLING HARD TO THE RIGHT, THEN IT STARTED TO PULSE AS IF THE ABS WAS STUCK ON. I TURNED
I BOUGHT A 2008 KIA SPORTAGE AT OSAGE BEACH MO ON JULY 12, 2016. I SENT IT TO GHANA IN AUGUST, 2016 AND CLEARED FROM THE PORT IN NOVEMBER, 2016. THE SAID CAR WAS PARKED FOR SEVERAL HOURS AT HOSPITAL ON AUGUST 21, 2018 AND CAUGHT FIRE AT 10.00PM THE SAME DAY. THE FIRE SERVICE WAS CALLED AND PUT OUT THE FIRE. AFTER EXAMINATION THE STATED IT WAS ELECTRICAL FIRE CAUSED BY THE WIRING HARNESS. I THEN LEARNT AFTER THE INCIDENT THAT THERE HAD BEEN A RECALL ( # 16V815000 / SC 138) ISSUED ON NOVEMBER 10
The contact owns a 2008 Kia Sportage. The contact stated that while the vehicle was parked and unattended, the vehicle caught fire. The ABS warning light was illuminated before the failure. The fire department extinguished the fire. There were no reported injuries. A police report was filed under case number 22027268. The local dealer was not contacted. The vehicle was not diagnosed or repaired. The manufacturer was not contacted. The failure mileage was approximately 112,000.
Was parked and after driving to pick up please came back out and it was in flames
Showing the 15 most serious of 98 complaints filed with NHTSA.
