2013 Ford E-150 Service and Repair Manual

This factory service and repair manual for the 2013 Ford E-150 is written for three body styles at once: a three-door extended cargo van, a three-door standard cargo van and a three-door standard passenger van, offered in Base, XL and XLT trim. Two naturally aspirated V8s are covered, the 4.6L overhead-cam flex-fuel engine and the 5.4L overhead-cam engine approved for LPG, flex-fuel or CNG. Procedures, specifications, torque values, wiring diagrams and diagnostics run system by system through engine, chassis and body.

Engines covered

• 4.6L V8 (281 cu in) — SOHC, naturally aspirated, flex-fuel
• 5.4L V8 (330 cu in) — SOHC, naturally aspirated, LPG (propane) or flex-fuel or CNG

Body styles covered

• 3-door extended cargo van
• 3-door standard cargo van
• 3-door standard passenger van

Trims covered

• Base
• XL
• XLT

Known issues on the 2013 E-150. The federal record holds five recalls for this year. Four of them come from wheelchair lift installers and cover platform mountings, cracked side plates and a lift cable that could contact a power lug; the fifth covers CNG cylinders on converted vans that could dislodge and leak. Owners have filed 19 complaints with NHTSA, weighted toward the power train and the engine, with one on steering. Transmission and engine procedures, torque values and diagnostics take up a substantial part of this manual.
