2001 GMC Jimmy Service and Repair Manual

This factory service and repair manual for the 2001 GMC Jimmy covers the Diamond Edition alongside the SL, SLE, SLS and SLT, in either the 4-door or the 2-door sport utility body. Every one of them uses the 4.3L overhead-valve V6, naturally aspirated and gasoline-fueled. The manual works outward from that engine through the transmission and axles, the steering and suspension, the brake system, climate control, the electrical system and the body, giving each its own procedures, specifications, torque values, wiring diagrams and diagnostic charts.

Engines covered

• 4.3L V6 (262 cu in) — OHV, naturally aspirated, gasoline

Body styles covered

• 4-door sport utility
• 2-door sport utility

Trims covered

• Diamond Edition
• SL
• SLE
• SLS
• SLT

Known issues on the 2001 Jimmy. This year draws three recalls. Two of them cover a multifunction switch that can develop an open circuit, which puts out the stop lamps and rear hazard lamps while leaving the high-mounted lamp and turn signals working, so the loss is easy to miss from the driver's seat. The third concerns seat belt buckle bases that were not properly heat treated and may not hold under crash loading. Owner complaints total 110, led by the suspension with 16 and by the service brakes and exterior lighting with 12 each. Lighting circuits and suspension torque values are documented here.
