1996 GMC Jimmy Service and Repair Manual

This factory service and repair manual for the 1996 GMC Jimmy serves both sport utility bodies, 4-door and 2-door, in Base, SL, SLE, SLS and SLT trim. All of them use the 4.3L overhead-valve V6, a naturally aspirated gasoline engine, which means one set of engine specifications and torque values covers the entire model year. Around that core, the manual sets out chassis, driveline, brake, steering, heating, electrical and body procedures, each with its own diagnostic charts and the wiring diagrams needed to trace a circuit end to end.

Engines covered

• 4.3L V6 (262 cu in) — OHV, naturally aspirated, gasoline

Body styles covered

• 4-door sport utility
• 2-door sport utility

Trims covered

• Base
• SL
• SLE
• SLS
• SLT

Known issues on the 1996 Jimmy. Eight recalls cover this year. An upper control arm ball joint can fail outright, which impairs or removes steering and can collapse the front suspension on that corner. Cracked solder joints on the wiper motor controller board leave the wipers working intermittently or not at all, a real problem in weather. Seat belt webbing on an outboard front position can separate in a frontal impact, leaving the occupant unrestrained in any secondary event. Of 508 owner complaints, 193 concern the service brakes and 68 visibility. Suspension, wiper and brake work all have full procedures and torque values here.
