1993 GMC C3500 Service and Repair Manual
This factory service and repair manual for the 1993 GMC C3500 covers four engines: the turbocharged 6.5L diesel V8, the naturally aspirated 6.2L diesel V8, and the 5.7L and 7.4L gasoline V8s. Those go into five different body configurations — standard cab, extended cab and crew cab pickups plus two- and four-door cab-and-chassis trucks — sold as Sierra, Sierra SLE or Sierra SLX. The result is a book that has to be precise about which figures belong to which combination, and it is, splitting procedures, specifications, torque values, wiring diagrams and diagnostics by system.
Engines covered
- 6.5L V8 (395 cu in) — OHV, turbocharged, diesel
- 7.4L V8 (454 cu in) — OHV, naturally aspirated, gasoline
- 6.2L V8 (379 cu in) — OHV, naturally aspirated, diesel
- 5.7L V8 (350 cu in) — OHV, naturally aspirated, gasoline
Body styles covered
- 2-door standard cab pickup
- 4-door cab & chassis
- 4-door crew cab pickup
- 2-door extended cab pickup
- 2-door cab & chassis
Trims covered
- Sierra
- Sierra SLE
- Sierra SLX
Known issues on the 1993 C3500. Two recalls apply. One covers replacement oil filters that may not seal against their mounting, letting engine oil out where it can catch fire; the other describes heat forcing transmission fluid through the vent tube with the same result. Owner complaints are heavier here, twenty in total, and they concentrate: five on steering, four on the power train and four on the service brakes. Those three systems get the manual's fullest treatment — steering gear and linkage, transmission and axle repair, and brake hydraulics — each with its specifications, torque values, wiring diagrams and diagnostic charts.
