1992 Toyota Pickup Service and Repair Manual

Fitment does real work on a truck cataloged this many ways: the 1992 Toyota Pickup ran two engine families across twenty separate trim entries carrying codes like R150, W55, A340F and A340H. This factory service and repair manual is tied to your exact year, engine and trim, so a clearance or torque figure meant for the 2.4L four (22RE) never lands on the 3.0L V6 (3VZ-E) by mistake.

Engines

• 2.4L 2366CC l4 GAS Naturally Aspirated
• 3.0L 2958CC V6 GAS SOHC Naturally Aspirated

Trims

• 1 Ton, Automatic
• 1 Ton, Standard, R150
• 1 Ton, Standard, W55
• Base, R150
• Base, W55
• DX, 2D Pickup Extra Cab, Automatic
• DX, 2D Pickup Extra Cab, Standard
• DX, 2D Pickup Extra Cab, Standard, R150
• DX, 2D Pickup Extra Cab, Standard, W55
• DX, 2D Pickup Extra Cab, Automatic, A340F
• DX, 2D Pickup Extra Cab, Automatic, A340H
• DX, 2D Pickup, Automatic
• DX, 2D Pickup, Standard
• DX, 2D Pickup, Standard, R150
• DX, 2D Pickup, Standard, W55
• DX, 2D Pickup
• SR5, Automatic
• SR5, Standard
• SR5, Standard, R150
• SR5, Standard, W55

Known issues on the 1992 Pickup. Three recalls are on federal record for this model year, and two of them fall on exterior lighting sold for the truck rather than on the truck as Toyota built it. The first covers aftermarket headlamps supplied for these vehicles that are missing the amber side reflex reflector; without those reflectors, lighting visibility may be affected. The second covers combination corner and bumper lamp assemblies sold as aftermarket equipment, where decreased lighting visibility may result in a vehicle crash. The third is a steering linkage recall, on the relay rod, covering certain pickup trucks and sport utility vehicles on which the steering wheel is repeatedly turned under conditions requiring high steering effort and power assist. If the vehicle is continued to be operated in this condition, the relay rod may fracture. Owners have filed 62 complaints for the year, and 9 technical service bulletins have been issued. The factory diagnostic and repair procedures behind each of those systems are here.

Whether it is the steering relay rod, a lighting fault, or routine service on the 2.4L four, it keeps you on Toyota's own procedure and the specification that belongs to your 1992 Pickup.
