2014 Volvo S60 Service and Repair Manual

This factory service and repair manual for the 2014 Volvo S60 runs to nine trim names, from Addition Plus, Ambition and Kinetic to Momentum, Momentum RD, R-Design, T5, T6 and T6 R-Design, all built as a four-door sedan. Its engine roster runs 1.6-liter (97 cu in) and 2.0-liter inline-fours, a 2.5-liter inline-five and a 3.0-liter (180 cu in) inline-six, with DOHC heads, turbochargers and gasoline throughout. It covers the engine, fuel system, ignition, cooling, transmission, drivetrain, brakes, suspension, steering and electrical system with procedures, specifications, torque values, wiring diagrams and diagnostics.

Engines covered

• 1.6L inline-four (97 cu in) — DOHC, turbocharged, gasoline
• 2.0L inline-four — DOHC, turbocharged, gasoline
• 2.5L inline-five — DOHC, turbocharged, gasoline
• 3.0L inline-six (180 cu in) — DOHC, turbocharged, gasoline

Body styles covered

• 4-door sedan

Trims covered

• Addition Plus
• Ambition
• Kinetic
• Momentum
• Momentum RD
• R-Design
• T5
• T6
• T6 R-Design

Known issues on the 2014 S60. The 2014 S60 has 3 recalls in the federal record. On certain 2014 S60 sedans with keyless ignition, the central module governing body electrics could misbehave, leaving the front wipers running whenever the ignition was on and disabling the turn signals, high beams or headlight switch; dealers upgraded its software. Certain cars were also recalled because the steel cable joining each front outboard seat belt to its anchor could weaken with age. Complaints number 25, with 12 on the engine, 3 on the electrical system, 3 on speed control, and 2 each on tires and visibility and wipers; 1 complaint reported a crash and 1 an injury. Lighting and wiper wiring diagrams and electrical system diagnostics follow these faults.
