2013 Volvo S60 Service and Repair Manual

This factory service and repair manual for the 2013 Volvo S60 carries a six-trim sedan line — Addition, Evolution, Kinetic, T5, T6 and T6 R-Design — on the four-door body. Every listed engine uses gasoline, a turbocharger and twin overhead camshafts, but cylinder counts range from four to six: a 1.6-liter (97 cu in) and a 2.0-liter (122 cu in) four, a 2.5-liter five and a 3.0-liter (180 cu in) six. It sets out procedures, specifications, torque values, wiring diagrams and diagnostics for the engine, fuel system, ignition, cooling, transmission, drivetrain, brakes, suspension, steering and electrical system.

Engines covered

• 1.6L inline-four (97 cu in) — DOHC, turbocharged, gasoline
• 2.0L inline-four (122 cu in) — DOHC, turbocharged, gasoline
• 2.5L inline-five — DOHC, turbocharged, gasoline
• 3.0L inline-six (180 cu in) — DOHC, turbocharged, gasoline

Body styles covered

• 4-door sedan

Trims covered

• Addition
• Evolution
• Kinetic
• T5
• T6
• T6 R-Design

Known issues on the 2013 S60. NHTSA lists 4 recalls for the 2013 S60. A manufacturing flaw in the restraint control unit of certain 2013 S60 cars could fire a seat belt pretensioner or the side curtain airbag with no crash, distracting the driver and blocking the view; the unit was replaced before those cars were sold. Certain cars may have a door latch with a part that breaks, so a door can look shut and then open while driving. Owners have filed 86 complaints — 36 on the engine, 7 each on air bags and the electrical system, and 5 each on the power train and service brakes. Crashes came up in 5 of those complaints and injuries in 5, with 1 citing a fire. Restraint wiring diagrams apply.
