1998 GMC Savana 3500 Service and Repair Manual
This factory service and repair manual for the 1998 GMC Savana 3500 opens on a range of five bodies, with cargo vans in standard and extended length, passenger vans in the same two lengths, and a two-door cutaway, each available in Base or SLE trim. Four overhead-valve engines are documented: the turbocharged 6.5L diesel V8, the 7.4L and 5.7L gasoline V8s, and the 4.3L gasoline V6. Specifications, torque values and diagnostic procedures are broken out by engine so the right numbers are easy to isolate.
Engines covered
- 6.5L V8 (395 cu in) — OHV, turbocharged, diesel
- 7.4L V8 (454 cu in) — OHV, naturally aspirated, gasoline
- 4.3L V6 (262 cu in) — OHV, naturally aspirated, gasoline
- 5.7L V8 (350 cu in) — OHV, naturally aspirated, gasoline
Body styles covered
- 3-door extended cargo van
- 3-door standard cargo van
- 3-door extended passenger van
- 3-door standard passenger van
- 2-door cutaway van
Trims covered
- Base
- SLE
Known issues on the 1998 Savana 3500. Two recalls sit on the federal record. The more serious one concerns front brake rotor and hub assemblies cast from out-of-specification gray iron, which can crack in service and, if driving continues, spread the crack around the wheel mounting bolt circle until the wheel separates. The other covers aftermarket corner and bumper lamps that lack the required amber side reflectors. Thirty-three owner complaints are logged, weighted toward the service brakes, the air bags and the electrical system, the three areas this manual's brake, restraint and wiring diagnostics are built to work through.
