1996 Mazda MX-6 Service and Repair Manual

This factory service and repair manual for the 1996 Mazda MX-6 deals with a 2-door coupe in three trims, Base, LS and M Edition, powered by either a 2.0L inline-four or a 2.5L V6. Dual overhead camshafts, natural aspiration and gasoline fuel are common to both engines. The manual lays out engine, fuel, ignition and cooling procedures with specifications and torque values, gives diagnostics and wiring diagrams for the electrical system, and documents the transmission, brakes, suspension and steering.

Engines covered

• 2.0L inline-four — DOHC, naturally aspirated, gasoline
• 2.5L V6 — DOHC, naturally aspirated, gasoline

Body styles covered

• 2-door coupe

Trims covered

• Base
• LS
• M Edition

Known issues on the 1996 MX-6. Federal records list 2 recalls against the 1996 MX-6. In certain cars with the SAS sensor unit, a minor impact to the underside could set off the air bags unexpectedly and injure occupants, so dealers reprogrammed that unit to cut down on needless deployments in low-speed underbody hits. Certain 1996 MX-6 vehicles were also recalled because grease inside the ignition switch may conduct current and overheat it, a fire risk; the remedy was a replacement switch. Air bags account for 7 of the 12 owner complaints; 3 complaints reported a crash and 1 an injury. For the air bag system and the ignition, the manual provides wiring diagrams, diagnostics and procedures.
