1982 Mazda 626 Service and Repair Manual

This factory service and repair manual for the 1982 Mazda 626 documents a car with one engine, a 2.0L inline-four using a single overhead camshaft, gasoline and natural aspiration. It came as a 4-door sedan or a 2-door coupe, in Base and LX trim. Procedures, specifications and torque values address the engine, fuel and ignition systems, cooling, the transmission and drivetrain, and the brakes, suspension and steering, with wiring diagrams for the electrical system.

Engines covered

• 2.0L inline-four — SOHC, naturally aspirated, gasoline

Body styles covered

• 4-door sedan
• 2-door coupe

Trims covered

• Base
• LX

Known issues on the 1982 626. Two recalls are recorded for the 1982 Mazda 626. The first applied to certain rear-wheel-drive cars used where roads are heavily salted: salt could break down the idler arm's dust seal and corrode its pin until the pin seized and snapped, which could cost the driver steering control. The fix was a replacement pin with better corrosion resistance. The second concerned certain cars repaired in a way that required loosening or removing the upper torso belt anchorage bolt, which might have gone back in incorrectly and could work loose in normal driving; after inspection, any bolt found improperly installed was removed and reinstalled correctly. Steering linkage and seat belt anchorage procedures, specifications and torque values are part of the manual.
