2011 Chevrolet HHR Service and Repair Manual

This factory service and repair manual for the 2011 Chevrolet HHR lists two engines and three trims: naturally aspirated flex-fuel inline-fours of 2.2 and 2.4 liters, 134 and 145 cubic inches, both twin-cam, in LS, LS Panel and LT versions of the two-door and four-door wagon. With the range this compact, the engine chapters branch once and the chassis, brake and body sections apply to everything, which shortens the path from a symptom to the specification that settles it.

Engines covered

• 2.2L inline-four (134 cu in) — DOHC, naturally aspirated, flex-fuel
• 2.4L inline-four (145 cu in) — DOHC, naturally aspirated, flex-fuel

Body styles covered

• 2-door wagon
• 4-door wagon

Trims covered

• LS
• LS Panel
• LT

Known issues on the 2011 HHR. Three recalls are on the federal record for this year, all of them centered on the ignition. The key can be taken out while the switch is not in the off position, which leaves the car able to roll away. Weight on the key ring can pull the switch from run into accessory, stalling the engine and leaving the air bags unable to deploy in a crash. Replacement switches sold for the repair share that weakness. Owners have logged 203 complaints, led by the fuel and propulsion system at 39, the electrical system at 29 and steering at 25.
