2014 Fiat 500 Service and Repair Manual

This factory service and repair manual for the 2014 Fiat 500 applies to a car that could be gasoline or battery-electric. The gasoline side offers a 1.4L (83 cu in) SOHC inline-four in naturally aspirated and turbocharged forms, and a battery-electric drive completes the list. There are ten trims in total, among them GQ, Turbo, Abarth and Abarth Cabrio, on a two-door hatchback or a two-door convertible. Procedures and specifications apply to both engines, the battery-electric drive, and the chassis, electrical system and bodies.

Engines covered

• 1.4L inline-four (83 cu in) — SOHC, naturally aspirated, gasoline
• 1.4L inline-four (83 cu in) — SOHC, turbocharged, gasoline
• Battery-electric drive (EV)

Body styles covered

• 2-door hatchback
• 2-door convertible

Trims covered

• Abarth
• Abarth Cabrio
• c Lounge
• c Pop
• E
• GQ
• Lounge
• Pop
• Sport
• Turbo

Known issues on the 2014 500. Three recalls appear on the federal record for the 2014 500. The first involves certain cars whose tire pressure warning lamp may not light when it should, so the car can be driven on underinflated tires; dealers reprogram the monitoring module. Certain cars with a manual transmission built within a set window risk a fractured clutch diaphragm spring, and certain battery-electric cars from a set window can slip into neutral when the drive control unit logs a fault. Owners lodged 124 complaints, chiefly power train 67, electrical system 22 and engine 19; 9 complaints reported a crash, 7 a fire and 6 an injury. The manual supplies procedures, specifications, wiring diagrams and diagnostics for those systems.
