2005 Volkswagen Touareg Service and Repair Manual

This factory service and repair manual for the 2005 Volkswagen Touareg spans three very different powerplants under one 4-door sport utility body. Gasoline versions use a naturally aspirated 3.2L V6 or 4.2L V8, both with double overhead cams, and the lineup also includes a turbocharged 5.0L V10 diesel with single overhead cams. Five trims are listed: Base, TDI, V6, V6 Premium and V8. The manual gives procedures, specifications, torque values, wiring diagrams and diagnostics for the engine, fuel, cooling, transmission, brake, suspension and electrical systems of this SUV.

Engines covered

• 3.2L V6 (195 cu in) — DOHC, naturally aspirated, gasoline
• 4.2L V8 — DOHC, naturally aspirated, gasoline
• 5.0L V10 (300 cu in) — SOHC, turbocharged, diesel

Body styles covered

• 4-door sport utility

Trims covered

• Base
• TDI
• V6
• V6 Premium
• V8

Known issues on the 2005 Touareg. The federal record holds 2 recalls for the 2005 Touareg. The first involved certain gasoline-powered vehicles whose fuel filter flange could crack and let fuel escape, a fire risk near any ignition source; dealers checked the flange and either replaced it or fitted a protective cover. The second concerned certain vehicles in which the passenger belt retractors could drop out of their child-seat locking mode with certain child restraints, leaving that restraint loose in a crash; a clip was added to the rear outboard belts. Owners filed 75 complaints, led by Fuel/Propulsion System (16) and Electrical System (14), and 1 complaint reported an injury. Fuel system, seat belt retractor and electrical procedures, specifications and wiring diagrams are included.
