1990 Ford Probe Service and Repair Manual

This factory service and repair manual for the 1990 Ford Probe documents three engines in the two-door hatchback across the GL, GT and LX trims: the turbocharged and the naturally aspirated versions of the 2.2L SOHC inline-four, each of 133 cubic inches, and the naturally aspirated 3.0L OHV V6 of 182 cubic inches, all gasoline. A four-cylinder with and without a turbocharger and an overhead-valve V6 make three distinct engine sections, and the procedures, specifications, torque values, wiring diagrams and diagnostics follow that split before covering the hatchback body and chassis that the three trims share.

Engines covered

• 2.2L inline-four (133 cu in) — SOHC, turbocharged, gasoline
• 2.2L inline-four (133 cu in) — SOHC, naturally aspirated, gasoline
• 3.0L V6 (182 cu in) — OHV, naturally aspirated, gasoline

Body styles covered

• 2-door hatchback

Trims covered

• GL
• GT
• LX

Known issues on the 1990 Probe. Four recalls are on federal record for the 1990 Probe. Two cover the automatic shoulder belts, whose rail can wear until the cable that retracts the buckle jams and the belt stops working, on the driver and passenger sides; another covers throttle levers bent during assembly that may stick and not return to idle. Owners have registered 355 complaints with NHTSA, and 287 of them concern seat belts, with the electrical system and engine cooling at ten apiece. The manual's seat belt procedures, throttle linkage specifications and electrical wiring diagrams cover exactly those systems.
