2016 Subaru Crosstrek Service and Repair Manual

This factory service and repair manual for the 2016 Subaru Crosstrek covers a year when the 4-door sport utility came with two versions of the same 2.0L flat-four. One is the conventional gasoline engine, naturally aspirated with double overhead cams; the other pairs that engine with a full hybrid system. The seven trims are Base, Hybrid, Hybrid Touring, Premium, Sport, Limited and Touring. Procedures, specifications and wiring diagrams are given for the engine, the hybrid electrical system, the transmission, brakes, suspension and body.

Engines covered

• 2.0L flat-four full hybrid — DOHC, naturally aspirated, gasoline
• 2.0L flat-four — DOHC, naturally aspirated, gasoline

Body styles covered

• 4-door sport utility

Trims covered

• Base
• Hybrid
• Hybrid Touring
• Limited
• Premium
• Sport
• Touring

Known issues on the 2016 Crosstrek. The federal record lists 1 recall for the 2016 Crosstrek. It concerns the brake light switch on certain vehicles: contamination can upset the switch so the brake lamps stay dark when the pedal is pressed, and on keyless-ignition cars the engine may refuse to start, while CVT or automatic models may stay locked in Park. Dealers fitted a new switch. Owners filed 134 complaints, led by the electrical system (38), power train (19), and engine and steering (14 each); 4 complaints reported a crash, 3 a fire and 1 an injury. The manual gives diagnostics and wiring diagrams for the electrical system and brake lighting.
