2011 GMC Canyon Service and Repair Manual

This factory service and repair manual for the 2011 GMC Canyon keeps four trims, Base, SLE, SLT and WT, and the same three-engine spread, the 5.3L OHV V8 next to the naturally aspirated DOHC 3.7L inline-five and 2.9L inline-four. Standard, extended and crew cabs all appear. What changes year to year on a truck like this is rarely the layout and usually the detail, so the specifications, torque values, wiring diagrams and diagnostic procedures are given per system for this model year specifically.

Engines covered

• 5.3L V8 (325 cu in) — OHV, naturally aspirated, gasoline
• 3.7L inline-five (223 cu in) — DOHC, naturally aspirated, gasoline
• 2.9L inline-four (178 cu in) — DOHC, naturally aspirated, gasoline

Body styles covered

• 4-door crew cab pickup
• 4-door extended cab pickup
• 2-door standard cab pickup

Trims covered

• Base
• SLE
• SLT
• WT

Known issues on the 2011 Canyon. Of the five recalls attached to the 2011 Canyon, the gravest involves rear axle cross pins that were not properly heat treated and could fracture, costing the driver directional control without warning. A second concerns a wiper motor crank arm nut left short of specification, which could stop the wipers sweeping, and a third covers hoods whose primary latch might not engage and could fly open in motion. Air bags lead the 23 owner complaints. Fastener torque values, chassis procedures and restraint diagnostics are exactly what this manual sets out.
