2010 Scion xB Service and Repair Manual

Fitment on the 2010 Scion xB is narrow by design: this service and repair manual is tied to the 2.4L four-cylinder (2AZ-FE) that powered the car that year and to the trim yours was built as, so the torque values, clearances and service intervals you work from are the ones published for this xB and not a figure carried over from an adjacent model year.

Engines

• 2.4L l4 GAS Naturally Aspirated

Trims

• Automatic
• Standard

Known issues on the 2010 xB. Eight recalls are on federal record for this model year, and four of them concern the same part: the passenger-side frontal air bag inflator module, where an inflator explosion — a rupture, in the earliest of the four — may result in sharp metal fragments striking the driver or other occupants, resulting in serious injury or death. A fifth covers the power window master switch, where grease lubricant may have been inconsistently applied to the sliding electrical contacts; if the sliding electrical contacts are not protected by lubricant, debris and moisture that get into the switch may cause a short circuit and the switch assembly may overheat and melt, increasing the risk of a fire. Another covers TRD brake kits sold as an optional accessory for the xB, whose brake hoses may fatigue and fail over time, and failure of a brake hose will reduce braking performance and increase the risk of a crash. The last two are label recalls: cars delivered without the requisite load carrying capacity modification labels do not meet the standard requirements, and a driver may overload a vehicle, which may increase the risk of a crash. Owners have filed 66 complaints for the year and 51 technical service bulletins are on record. The diagnostic and repair procedures behind those systems are here.

Whether you are tracing an overheating window switch, replacing a brake hose to spec or simply keeping to a service interval, it holds you to the OEM procedure and the correct figure for your specific 2010 xB.
