2009 Lexus LS 460 Service and Repair Manual
Regular price
$34.99 USD
Unit price
Covers all 2009 LS 460 trims — AWD, RWD ·
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.7
·
Trusted by 14,000+ mechanics & DIYers
End of preview
Unlock the full manual
Complete repair procedures
Wiring diagrams & schematics
Torque specifications
Full search & bookmarks
$34.99
2009 Lexus LS 460 Service and Repair Manual
Regular price
$34.99 USD
Unit price
Matched to the 2009 model year, to the 4.6L V8 (1UR-FSE), and to whichever drivetrain your car left the line with, this Lexus LS 460 service and repair manual holds you to the clearances and torque sequences Lexus published for this specific car rather than a close-enough figure carried over from a neighboring model year.
Engines
- 4.6L V8 GAS Naturally Aspirated
Trims
- AWD
- RWD
Known issues on the 2009 LS 460. Two recalls are on federal record for this model year. The first covers the gasoline fuel delivery system, specifically the hoses, lines and fittings: anti-corrosion plating remnants can let fuel leak from the point where the fuel pressure sensor attaches to the fuel delivery pipe, and a fuel leak in the presence of an ignition source increases the risk of a fire. The second covers the electric power assist steering system: improper activation of the steering system protection logic can cause the steering wheel to become off-centered by up to 90 degrees, which may happen after the driver has fully turned the wheel in one direction and then quickly attempts to turn it back to the center position, and should this occur while driving, the risk of a crash is increased. No complaints have been filed for the year and no technical service bulletins are on record for it. The diagnostic and repair procedures behind both of those systems are here.
From tracing a fuel delivery line at the pressure sensor to checking the variable gear ratio steering or working through a scheduled service on the 1UR-FSE, it keeps you on the OEM procedure and the correct specification for your specific 2009 LS 460.
Toyota Motor Engineering & Manufacturing (Toyota) is recalling certain model year 2007-2010 Lexus LS vehicles manufactured May 9, 2006, to July 20, 2010, 2006-2011 Lexus GS vehicles manufactured January 6, 2005, to September 10, 2010, and 2006-2011 Lexus IS vehicles manufactured August 30, 2005, to September 10, 2010. Due to anti-corrosion plating remnants, fuel may leak from where the fuel pressure sensor is attached to the fuel delivery pipe.
Consequence
A fuel leak in the presence of an ignition source increases the risk of a fire.
Remedy
Toyota will notify owners, and dealers will clean and reseal the fuel pressure sensor mounting area, free of charge. The recall began March 3, 2015. Owners may contact Toyota customer service at 1-800-331-4331.
TOYOTA IS RECALLING CERTAIN MODEL YEAR 2009 AND 2010 LEXUS LS460 AND LS600 VEHICLES MANUFACTURED FROM AUGUST 20, 2009 THROUGH MAY 13, 2010. A PROGRAMMING CHANGE OF THE STEERING CONTROL ECU FOR THE VARIABLE GEAR RATIO STEERING (VGRS) SYSTEM CAN CAUSE IMPROPER ACTIVATION OF THE STEERING SYSTEM PROTECTION LOGIC DESIGNED TO PROTECT THE SYSTEM WHEN LARGER THAN NORMAL STEERING INPUTS ARE APPLIED AT A FULLY TURNED POSITION.
Consequence
IMPROPER ACTIVATION OF THE STEERING SYSTEM PROTECTION LOGIC CAN CAUSE THE STEERING WHEEL TO BECOME OFF-CENTERED UP TO 90 DEGREES. THIS MAY OCCUR AFTER THE DRIVER HAS FULLY TURNED THE STEERING WHEEL IN ONE DIRECTION THEN QUICKLY ATTEMPTS TO TURN IT BACK TO THE CENTER POSITION. SHOULD THIS OCCUR WHILE DRIVING, THE RISK OF A CRASH IS INCREASED.
Remedy
TOYOTA WILL NOTIFY OWNERS AND LEXUS DEALERS WILL REPLACE THE STEERING CONTROL ECU FREE OF CHARGE. THE SAFETY RECALL BEGAN ON JULY 12, 2010. OWNERS MAY CONTACT TOYOTA AT 1-800-331-4331.
Lexus Safety Recall and Service Campaign - Technician Certification Requirements 4.13.2022
TSB: This Service Bulletin includes procedures to replace damaged or loose front carpet floor retainer(s) without replacing the carpet assembly. Follow the Repair Procedure in this bulletin to replace the loose or damaged carpet floor retai
TSB: Some 2005 ? 2022 model year Lexus vehicles that have undergone water intrusion may exhibit a condition in which a musty smell is present. Follow the procedures in this bulletin to remediate the odor and address this condition. The purp
POL: This consolidated Tire Warranty Guide contains the complete warranty terms for all brands of ground and spare tires currently in use by Lexus. This information must be kept near the point of vehicle sale and be available to any custome
HDD Navigation Map Update Process - Lexus models equipped with Hard Disk Drive (HOD) Navigation require a Special Service Tool and follow a unique process for updating map, points of interest, and system software. Instead of individual DVDs
World Standard Automatic Transmission Fluid
Theft Deterrent/Keyless Entry.
Brake Pedal Force Gauge SST for Parking Brake Inspection.
Showing the 8 most recent of 167 technical service bulletins on file with NHTSA.
No complaints filed
No consumer complaints on file with NHTSA for the 2009 Lexus LS 460.
