2004 Chevrolet C5500 Kodiak Service and Repair Manual

This factory service and repair manual for the 2004 Chevrolet C5500 Kodiak documents four order codes — C5C042, C5E042, C5U042 and C5V042 — over four body types: crew cab and chassis, motorhome cutaway, cutaway chassis and two-door conventional cab and chassis. Two engines were on offer, the turbocharged 6.6-liter diesel of 403 cubic inches and the 8.1-liter gasoline V8 of 496, and the manual separates their fuel, ignition and cooling material while treating the chassis beneath them as common.

Engines covered

• 6.6L V8 (403 cu in) — OHV, turbocharged, diesel
• 8.1L V8 (496 cu in) — OHV, naturally aspirated, gasoline

Body styles covered

• Cab & chassis, crew cab
• Motorhome, cutaway
• Cab & chassis, cutaway
• 2-door cab & chassis, conventional

Trims covered

• C5C042
• C5E042
• C5U042
• C5V042

Known issues on the 2004 C5500 Kodiak. A single owner complaint is recorded against the 2004 Kodiak, and it concerns the fuel system. That is a narrow signal, but fuel work on this chassis is anything but narrow: the manual documents tank, lines and filtration for both engines, along with the injection pump, glow plug circuit and turbocharger diagnosis the 6.6-liter diesel requires and the fuel delivery and ignition specifications for the 8.1-liter gasoline V8. Torque values, wiring diagrams and diagnostic charts accompany each of those procedures.
