2023 Volkswagen Crafter Van Service and Repair Manual

This factory service and repair manual for the 2023 Volkswagen Crafter Van documents the turbocharged 2.0L inline-four diesel with DOHC in a wide spread of versions. The trim list runs to seven entries, with Cargo, Chasis and Pasajeros variants in several ratings, and the body styles include a 2-door cab and chassis plus standard and extended cargo and passenger vans with 4 doors. Procedures, specifications and torque values address the engine, fuel, cooling, transmission and chassis systems.

Engines covered

• 2.0L inline-four (120 cu in) — DOHC, turbocharged, diesel

Body styles covered

• 2-door cab & chassis
• 4-door standard cargo van
• 4-door extended cargo van
• 4-door standard passenger van
• 4-door extended passenger van

Trims covered

• Cargo 3.5t
• Cargo 4.9t
• Cargo 5.0t
• Chasis 3.5t
• Chasis 5.0t
• Pasajeros 3.5t
• Pasajeros 5.0t

Known issues on the 2023 Crafter Van. The Chasis trims, the cargo vans and the passenger vans all use the turbocharged 2.0L diesel, and the manual gives procedures, specifications and diagnostics for the engine, its turbocharged induction, the fuel system and cooling. Torque values carry through the transmission, drivetrain, brakes and suspension. Wiring diagrams map the electrical system, and body procedures address the cab and chassis as well as the enclosed vans.
