2019 Volkswagen Crafter Van Service and Repair Manual

This factory service and repair manual for the 2019 Volkswagen Crafter Van documents the turbocharged 2.0L inline-four diesel, a DOHC engine, as fitted to four 4-door body styles: the standard passenger van, the extended passenger van, the standard cargo van and the extended cargo van. Buyers chose between Cargo and Pasajeros trims. Wiring diagrams for the electrical system join engine, fuel, cooling and transmission procedures, and specifications and torque values reach the chassis.

Engines covered

• 2.0L inline-four (120 cu in) — DOHC, turbocharged, diesel

Body styles covered

• 4-door extended passenger van
• 4-door standard cargo van
• 4-door extended cargo van
• 4-door standard passenger van

Trims covered

• Cargo
• Pasajeros

Known issues on the 2019 Crafter Van. On the diesel, the fuel system and turbocharged induction call for accurate specifications, and the manual supplies them together with cooling system procedures and engine torque values. Its diagnostics help isolate faults in the engine and electrical system, and its wiring diagrams trace circuits through the cab and passenger area. Brake, suspension and steering procedures apply across the cargo and passenger bodies in standard and extended form.
