2020 Volkswagen Crafter Van Service and Repair Manual

This factory service and repair manual for the 2020 Volkswagen Crafter Van covers a range offered in the Cargo and Pasajeros trims. Body styles are the 4-door standard and extended cargo vans and the 4-door standard and extended passenger vans. The engine list is short: a 2.0L inline-four turbodiesel with double overhead camshafts. Engine, fuel system and cooling procedures come with specifications and torque values, while wiring diagrams and diagnostics address the electrical system.

Engines covered

• 2.0L inline-four (120 cu in) — DOHC, turbocharged, diesel

Body styles covered

• 4-door extended passenger van
• 4-door standard cargo van
• 4-door extended cargo van
• 4-door standard passenger van

Trims covered

• Cargo
• Pasajeros

Known issues on the 2020 Crafter Van. The transmission, drivetrain and brakes carry the van and its load, and the manual gives the torque values and specifications to keep them right. It pairs those with procedures and diagnostics for the DOHC diesel, its turbocharged induction, its fuel system and its cooling. Wiring diagrams cover the electrical system, and suspension, steering and body procedures apply to the cargo and passenger versions in standard and extended length.
