2017 Mercedes-Benz Metris Service and Repair Manual
2017 Mercedes-Benz Metris service and repair manual — a detailed, factory-style reference for maintenance, diagnostics, and repair. Use it to confirm correct procedures, specifications, and system coverage before you start work.
Designed for technicians and DIY owners, this manual helps you troubleshoot accurately, follow step-by-step repair procedures, and reference wiring diagrams and system sections quickly while you work.
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Daimler Vans USA, LLC (DVUSA) is recalling certain 2016-2017 Mercedes-Benz Metris vehicles. The fuel hose in the engine compartment may leak at the lower connecting point of the transition hose, betw
A fuel leak in the presence of an ignition source can increase the risk of a fire.
DVUSA will notify owners, and dealers will replace the affected hose and clamp, free of charge. The
Daimler Vans USA, LLC (DVUSA) is recalling certain 2017-2018 Mercedes-Benz Metris vehicles. The drive shaft securing bolts may loosen at the automatic transmission flange.
If the bolts loosen and fall out, the driveshaft may separate causing a loss of drive, thereby incre
DVUSA will notify owners, and dealers will replace the transmission flange, securing bolts, and clea
Daimler Vans USA, LLC (DVUSA) is recalling certain model year 2017 Mercedes-Benz Metris Vans manufactured September 9, 2016, to September 28, 2016. The affected vehicles have a passenger air bag that
An improperly vented air bag may not protect the front passenger as expected, increasing the risk of
DVUSA will notify owners, and authorized Mercedes-Benz Sprinter dealers will replace the front passe
Daimler Vans USA, LLC (DVUSA) is recalling certain 2015-2018 Mercedes-Benz Metris vehicles. A defective memory chip in the rearview camera may cause the display image to freeze.
A frozen rearview image does not show the live view of what is currently behind the vehicle, increas
Dealers will replace the rearview camera, free of charge. Owner notification letters were mailed Fe
Daimler Vans USA, LLC (DVUSA) is recalling certain 2016-2017 Metris vehicles sold, or ever registered in Connecticut, Delaware, Illinois, Indiana, Iowa, Kentucky, Maine, Maryland, Massachusetts, Mich
Loss of power steering assist would require a higher steering effort, especially at lower speeds, wh
DVUSA will notify owners, and dealers will replace the aluminum bolts with steels bolts, free of cha
Daimler Vans USA, LLC (DVUSA) is recalling certain 2016-2019 Mercedes-Benz Metris vehicles. The integrated backup battery compartment located underneath the front passenger's seat may not have its o
If conductive material, such as metal, unintentionally drops into the opening and contacts the termi
DVUSA will notify owners, and Mercedes-Benz dealers will install covers over the battery compartment
Daimler Vans USA, LLC (DVUSA) is recalling certain 2017-2022 Mercedes-Benz Metris vehicles. The connection of the upper and lower fuel hoses to the engine may be insecure, which can result in a fuel
A fuel leak in the presence of an ignition source can increase the risk of a fire.
Dealers will inspect and repair the fuel hose connections, and replace the clamps and fuel hose, as
Daimler Vans USA, LLC (DVUSA) is recalling certain 2016-2021 Mercedes-Benz Metris vehicles. The brake fluid reservoir may be incorrectly mounted, which can allow it to detach.
A detached brake fluid reservoir can leak brake fluid, increasing the risk of a crash.
Dealers will inspect and repair the brake fluid reservoir mounting, as necessary, free of charge. O
Daimler Vans USA, LLC (DVUSA) is recalling certain 2016-2018 Mercedes-Benz Metris vans. The value for the maximum combined load weight capacity of the tires is incorrect. As such, these vehicles fai
An overloaded vehicle may cause tire failure, increasing the risk of a crash.
Dealers will install corrected labels on the B-pillar and fuel filler door. Dealers will also inspe
Daimler Vans USA LLC (DVUSA) is recalling certain 2016-2017 Mercedes-Benz Metris vehicles. These vans were to be equipped with the Blind Spot Monitoring (BSM) feature, however, the installed instrume
If a vehicle is in the driver's blind spot, but the BSM system does not warn the driver, there would
DVUSA will notify owners, and dealers will install the correct instrument cluster and steering wheel
Daimler Vans USA, LLC (DVUSA) is recalling certain 2016-2020 Mercedes-Benz Metris and 2019-2020 Mercedes-Benz Sprinter vehicles. The software design of the communication module may fail to communicat
Failure of the eCall system may result in emergency responders being dispatched to the wrong locatio
DVUSA will notify owners, and dealers will update the software communication module for the automati
Check engine light on and FC P146264 stored in engine and fuel pump control units Complaint Check engine light active and FC P146264 Temp. and pressure sensor B4/15 is stored in Engine control unit and Fuel pump control unit. Cause Software
Complaint Transmission control unit Y3/8n4 (fully integrated transmission control unit (VGS)) not listed in quick test and/or no communication possible with VGS. Cause Transmission control unit Y3/8n4 Remedy For vehicles with 722.9 transmis
Check engine light illuminated - Fault code current P04D-B79 The crankcase ventilation system is interrupted. Complaint: Check engine light on. Fault code P04DB79 is current in the engine control module (N3/10). Cause: Open circuit or high
Warning Lamp "Washer Fluid Empty" Yet Reservoir Is Not Empty Complaint: Warning lamp "washer fluid empty", even thought the washer fluid reservoir is full Cause: Insufficient electrical conductivity of the washer fluid, as the washer fluid
Complaint Fault code P06DA00 is found current or stored in engine control unit. Check engine light may be activated. Cause Various causes Remedy Up to Model year 2018: Fault code P06DA00 can be disregarded if not activating the check engine
M274 poly-V belt squeaking noises, falls off, not aligned, broken
SMOG/Emissions Test fail due to one or more Readiness Monitors not set Complaint: The vehicle has failed the State Emissions Certification because one or more of the OBDII readiness monitors are not completely set. Cause: One or more of the
Complaint: Noises when reversing slowly <5 km/h (squeaking) Cause: There is a seal in the electric drivetrain that seals off the coolant system from the electric motor. This seal is moistened with coolant during forward travel. As a result
Showing the 8 most recent of 31 technical service bulletins on file with NHTSA.
I am filing a formal safety complaint regarding my Mercedes-Benz Metris serviced at Mercedes-Benz Coconut Creek (Florida) under Recall VS2LAS561 â 9789VMCRC (Customer Service Case #20781216). On Fe
I am filing a formal safety complaint regarding my Mercedes-Benz Metris serviced at Mercedes-Benz Coconut Creek (Florida) under Recall VS2LAS561 â 9789VMCRC (Customer Service Case #20781216). On Fe
I am filing a formal safety complaint regarding my Mercedes-Benz Metris serviced at Mercedes-Benz Coconut Creek (Florida) under Recall VS2LAS561 â 9789VMCRC (Customer Service Case #20781216). On Fe
I have had 2 major and costly repairs/issues with the engine and its oil system. These are detailed below. I have also received multiple collision or seatbelt dash alerts when no one is near my vehi
I have had 2 major and costly repairs/issues with the engine and its oil system. These are detailed below. I have also received multiple collision or seatbelt dash alerts when no one is near my vehi
Showing the 5 most serious of 37 complaints filed with NHTSA.
