2005 Ford E-150 Club Wagon Service and Repair Manual

This factory service and repair manual for the 2005 Ford E-150 Club Wagon covers the two-door standard passenger van in Chateau, XL and XLT form. Power comes from one of two naturally aspirated gasoline V8s, the 281-cubic-inch 4.6L overhead-cam or the 330-cubic-inch 5.4L overhead-cam, and both are documented in full. The book is organized by system, so procedures, specifications, torque values, wiring diagrams and diagnostics for the engine, the driveline, the chassis and the body electrics each occupy their own part.

Engines covered

• 4.6L V8 (281 cu in) — SOHC, naturally aspirated, gasoline
• 5.4L V8 (330 cu in) — SOHC, naturally aspirated, gasoline

Body styles covered

• 2-door standard passenger van

Trims covered

• Chateau
• XL
• XLT

Known issues on the 2005 E-150 Club Wagon. The federal record shows four recalls. Two point at fuel containment, a batch of replacement tanks with an extra sensor opening that may not have been sealed and aftermarket fuel filters whose quick connectors could work free of the tube, and two point at wheelchair lifts added after the wagon left Ford. Owners have filed 26 complaints with NHTSA, spread evenly over service brakes, engine and engine cooling, and fuel. Brake, cooling and fuel procedures with their torque values and diagnostics all sit in this manual.
