2003 Ford E-150 Club Wagon Service and Repair Manual

This factory service and repair manual for the 2003 Ford E-150 Club Wagon deals with a passenger van sold in one body, a two-door standard wagon, and three trims, Chateau, XL and XLT. Three gasoline engines were available: the 4.2L overhead-valve V6 of 256 cubic inches, the 4.6L overhead-cam V8 of 281 and the 5.4L overhead-cam V8 of 330, all naturally aspirated. Procedures, specifications, torque values, wiring diagrams and diagnostics are set out system by system, so the correct data for a given engine is easy to find.

Engines covered

• 4.2L V6 (256 cu in) — OHV, naturally aspirated, gasoline
• 4.6L V8 (281 cu in) — SOHC, naturally aspirated, gasoline
• 5.4L V8 (330 cu in) — SOHC, naturally aspirated, gasoline

Body styles covered

• 2-door standard passenger van

Trims covered

• Chateau
• XL
• XLT

Known issues on the 2003 E-150 Club Wagon. Four recalls sit on the federal record for this wagon. Two concern aftermarket combination corner and bumper lamps that did not meet federal lighting requirements, one concerns a cruise control fuse placed in the output circuit rather than the power feed, and one concerns missing fuel tank brackets and outriggers on the school bus chassis option. Owners have filed 215 complaints with NHTSA, concentrated on engine and engine cooling, the electrical system and the fuel system. All three have their own procedures, wiring diagrams and diagnostics here.
