1990 Mercury Topaz Service and Repair Manual

This factory service and repair manual for the 1990 Mercury Topaz reaches ten trims — GS through XR5, with an all-wheel-drive counterpart for five of them — on one engine and two bodies. The engine is the naturally aspirated 2.3-liter OHV inline-four of 140 cubic inches; the bodies are the two-door and four-door sedans. Ten equipment levels mean the wiring diagrams and component locations carry most of the variation, while engine mechanical, fuel, ignition and emissions specifications stay constant across the range.

Engines covered

• 2.3L inline-four (140 cu in) — OHV, naturally aspirated, gasoline

Body styles covered

• 2-door sedan
• 4-door sedan

Trims covered

• GS
• GS AWD
• LS
• LS AWD
• LTS
• LTS AWD
• Sport
• Sport AWD
• XR5
• XR5 AWD

Known issues on the 1990 Topaz. Two recalls are on the federal record. Threaded parts inside the frontal air bag inflator can be damaged during assembly and separate when the inflator fires, releasing hot combustion gases into the passenger compartment. The other is an ignition switch that can short internally, overheating and smoking, with fire in the steering column possible. Complaints total 65, with 22 on the electrical system, 9 on engine and cooling and 6 on vehicle speed control — restraint, column and throttle systems that this manual covers with procedures, diagrams and torque values.
