1987 Dodge W100 Service and Repair Manual

This factory service and repair manual for the 1987 Dodge W100 concerns a 2-door standard cab pickup in Custom trim, powered by one of three overhead-valve gasoline engines. The six-cylinder option is a 3.7L inline-six; the V8 options measure 5.2L and 5.9L. No forced induction appears on any of them. The manual carries procedures, specifications, torque values, wiring diagrams and diagnostics for the engine, fuel system, ignition, cooling, transmission, clutch, drivetrain, brakes, suspension, steering and electrical system.

Engines covered

• 3.7L inline-six (225 cu in) — OHV, naturally aspirated, gasoline
• 5.2L V8 (318 cu in) — OHV, naturally aspirated, gasoline
• 5.9L V8 (360 cu in) — OHV, naturally aspirated, gasoline

Body styles covered

• 2-door standard cab pickup

Trims covered

• Custom

Known issues on the 1987 W100. Two recall campaigns were filed against the 1987 W100. Certain 1987 W100 pickups with the inline-six engine and a manual transmission had plastic hydraulic clutch parts that exhaust heat could damage during long cold running at raised engine speed, leading to fluid leaks and a risk of a small fire where fluid met the hot exhaust; heat shields were added between them. Certain trucks with a six-and-a-half-foot box, fuel injection and no rear bumper could have the box crossmember hit the pump module fuel line in a rear collision and leak fuel, so brackets were installed underneath. Clutch hydraulics and fuel system procedures, specifications and torque values in the manual apply.
