2024 Volkswagen Constellation Service and Repair Manual

This factory service and repair manual for the 2024 Volkswagen Constellation covers four trims, 17.280, 19.360, 24.280 and 31.330, built as either a 2-door tractor truck or a 2-door straight truck in long conventional form. Two turbocharged diesel inline-sixes are listed: a 6.9L and a 540-cubic-inch 8.9L with SOHC. Procedures, specifications and torque values address the engines, fuel and cooling systems, transmission, drivetrain, brakes, suspension and steering, and wiring diagrams and diagnostics address the electrical system.

Engines covered

• 6.9L inline-six — turbocharged, diesel
• 8.9L inline-six (540 cu in) — SOHC, turbocharged, diesel

Body styles covered

• 2-door tractor truck, long conventional
• 2-door straight truck, long conventional

Trims covered

• 17.280
• 19.360
• 24.280
• 31.330

Known issues on the 2024 Constellation. For the 2024 Constellation, the manual supports both diesel engines at the level of their systems: the 6.9L six and the SOHC 8.9L six have procedures and diagnostics for turbocharged induction, fuel delivery and cooling. Torque values back the transmission and drivetrain. The brakes, suspension and steering of the tractor and straight trucks are given specifications, and wiring diagrams map the electrical system of the four trims.
