2018 Volkswagen Constellation Service and Repair Manual

This factory service and repair manual for the 2018 Volkswagen Constellation covers the 17.280 and 24.280, both 2-door straight trucks in long conventional form. A turbocharged 6.9L diesel inline-six powers them. Where the truck needs attention, whether at the engine, the fuel or cooling system, the transmission and drivetrain, or the brakes, steering and suspension, the manual provides procedures, specifications and torque values, with wiring diagrams and diagnostics for the electrical system.

Engines covered

• 6.9L inline-six — turbocharged, diesel

Body styles covered

• 2-door straight truck, long conventional

Trims covered

• 17.280
• 24.280

Known issues on the 2018 Constellation. For the 2018 Constellation, the manual stays at the level of the truck's major systems. Its diesel six, a 6.9L turbocharged unit, is supported with procedures and diagnostics for fuel and cooling. Torque values and specifications cover the transmission and drivetrain, the brakes and the steering and suspension. Wiring diagrams map the electrical system through the long conventional straight-truck body for both trims.
