2016 Chevrolet Spark Classic Service and Repair Manual

This factory service and repair manual for the 2016 Chevrolet Spark Classic is built around a naturally aspirated 1.2L DOHC inline-four of 74 cubic inches, mounted in a four-door hatchback sold as Cargo, LS, LT and LTZ. One engine across four trims means the engine mechanical, fuel, ignition and emissions specifications apply to any of them, and the same holds for the brake, steering and suspension work; what changes between trims is equipment, and the wiring diagrams and body sections carry that.

Engines covered

• 1.2L inline-four (74 cu in) — DOHC, naturally aspirated, gasoline

Body styles covered

• 4-door hatchback

Trims covered

• Cargo
• LS
• LT
• LTZ

Known issues on the 2016 Spark Classic. One recall is recorded federally, covering the front passenger air bag: if a young child is seated improperly and unbelted in that seat, the deploying bag can injure the child's neck. The complaint record runs to 42 entries and is dominated by the service brakes at 19, ahead of the air bags at 5 and the electrical system at 4. Brake hydraulic and friction procedures with their specifications, restraint system diagnosis, and the wiring diagrams behind both are covered in this manual.
