2004 Lexus RX 330 Service and Repair Manual
Regular price
$34.99 USD
Unit price
Covers all 2004 RX 330 trims — AWD, FWD ·
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.7
·
Trusted by 14,000+ mechanics & DIYers
End of preview
Unlock the full manual
Complete repair procedures
Wiring diagrams & schematics
Torque specifications
Full search & bookmarks
$34.99
2004 Lexus RX 330 Service and Repair Manual
Regular price
$34.99 USD
Unit price
Written against the 2004 RX 330 specifically, this Lexus service and repair manual ties every clearance, torque value and diagnostic tree to the 3.3L V6 (3MZ-FE) and the driveline your vehicle actually left the assembly plant with, instead of a figure carried over from an adjacent model year.
Engines
- 3.3L V6 GAS Naturally Aspirated
Trims
- AWD
- FWD
Known issues on the 2004 RX 330. Five recalls are on federal record for this model year. One covers engine and engine cooling: the amount of adhesive applied between the outer ring and the torsional rubber damper of the crankshaft pulley may be inadequate, and if the adhesive is insufficient there is a possibility that the outer ring may become misaligned. In some cases the belt for the power steering pump may become detached from the pulley, which could result in a loss of power steering and a sudden increase in steering effort. Two more concern the accelerator pedal. On the first, if the forward retention clip that secures the floor carpet cover in front of the center console is not installed properly, the cover may lean toward the accelerator pedal and interfere with the accelerator pedal arm; if that occurs, the pedal may temporarily become stuck in a partially depressed position rather than return to the idle position, which may result in unintended and sustained vehicle speeds and make it difficult to stop. On the second, the two retaining clips for the driver's side forward center console can become loose, and if both clips separate from the floor carpet cover the cover may lean toward the accelerator pedal, causing interference with the accelerator pedal rod, a condition that may interfere with the accelerator pedal returning to the idle position. A fourth covers the rear seat belts: the anchor bolt for the rear, left-hand side seat belt buckle directly behind the driver's seat does not have sufficient strength, so the rear seat occupant may not be properly restrained in the event of a crash. The fifth covers the brake light switch, where a silicon oxide build-up on the contacts inside the switch can make it inoperable; if the switch is inoperable, the brake lights will not illuminate. Owners have filed 327 complaints for the year, and no technical service bulletins are on record. The diagnostic and repair procedures behind each of those systems are here.
From a dead brake light to the console carpet clips around the accelerator pedal or a scheduled service interval, it keeps you on the OEM procedure and the correct specification for your specific 2004 RX 330.
