1986 GMC S15 Jimmy Service and Repair Manual

This factory service and repair manual for the 1986 GMC S15 Jimmy lists the two-door sport utility in Base, Gypsy and Sierra Classic trim, with a 2.8L overhead-valve V6 of 173 cubic inches or a 2.5L overhead-valve inline-four of 151 cubic inches under the hood. It is written for a technician working through a system rather than chasing a symptom, which is why its procedures, specifications, torque values, wiring diagrams and diagnostics are grouped by engine, driveline, chassis, brake and electrical system.

Engines covered

• 2.8L V6 (173 cu in) — OHV, naturally aspirated, gasoline
• 2.5L inline-four (151 cu in) — OHV, naturally aspirated, gasoline

Body styles covered

• 2-door sport utility

Trims covered

• Base
• Gypsy
• Sierra Classic

Known issues on the 1986 S15 Jimmy. Three recalls are on the federal record for this year. One concerns replacement lamps built without the amber side reflectors federal rules require. Another involves certification labels printed with tire and wheel information that may not match the vehicle. The third covers a push-pull headlight switch whose contacts can become intermittent, so the headlights flicker or go out without warning. Three owner complaints are logged, one each on steering, the fuel system and seat belts, all systems this manual documents with their own procedures and specifications.
