Yamaha YDX-TORC Service and Repair Manual

For the YDX-TORC, Yamaha's service part number is LIT-15616-00-01, and the model code recorded against it is YTORCLTYB. No other model is listed with it, so the whole book applies to this bicycle.

Confirm the code on the frame label before ordering.

Contents

• Specifications and tightening torques
• Periodic inspection and adjustment schedule
• Drive unit removal, inspection and refitting
• Battery and wiring harness service
• Diagnosis keyed to the system's indications

Suspension, brake, wheel and drivetrain procedures follow Yamaha's own sequence, with fastener values stated at the step where they are needed. Specifications are given as limits, which is what lets a worn component be judged rather than guessed at.
