Yamaha CROSSCONNECT Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

One book, three bicycles. Yamaha published LIT-15616-00-02 to cover the CROSSCONNECT along with the CROSSCORE and URBANRUSH, and the code recorded for this model is CCNTLPOL.

That shared authorship is useful and worth a moment's care: where the three frames differ in specification, the tables say so, and a figure read from the wrong column will be wrong on your bicycle.

Also covered

  • CROSSCORE
  • URBANRUSH

Content includes assembly and adjustment specifications, tightening torques, periodic inspection, drive unit and battery service, harness routing, and the diagnostic sequence Yamaha wrote around the system's own error indications. Brake, wheel and drivetrain procedures are given in the factory order.

Confirm CCNTLPOL on the frame label before ordering.
