2025 Yamaha WOLVERINE RMAX4 1000 LE Compact Service and Repair Manual

Yamaha part LIT-11616-38-21 is the 2025 service manual for the compact RMAX4 1000 machines, and the LE Compact is coded YXF10WRLSL.

The R-Spec Compact and XT-R Compact are covered in the same volume. That matters when you are diagnosing something: the shared systems are described once, in full, instead of being split across separate books with slightly different wording.

Scope of the procedures

• Removal, inspection and installation in factory order
• Torque values and service limits at each step
• Wiring diagrams for the machine as built
• Troubleshooting organised from the symptom down

Check the code on your machine before ordering. The compact and full-length RMAX4 chassis carry different codes and different manuals, and the difference is easy to miss when the machines are parked apart. The plate settles it in a second, and the part number above settles the rest.
