2025 Yamaha TT-R230 Service and Repair Manual

$29.99 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Fitment first

Part number LIT-11616-38-05. Model code TTR230S. Those are the two things worth checking before anything else, because they are what tie this reference to a 2025 TT-R230 and nothing else.

Yamaha drew the coverage to include both the 2025 and 2026 model years, which tells you the machine carried over between them. A shop working on either bike uses the same figures.

Inside, the writing assumes you have the bike on a stand and the tools out. Service intervals and adjustment specifications come first, then engine work in the order the factory wants it done, then the chassis, then the electrical system with Yamaha's own wiring diagrams. Troubleshooting is arranged by symptom, so a bike that will not start or will not charge sends you to a defined sequence of checks rather than guesswork.

It is the dealer reference, not a summary of one.
